Samco Trade API Documentation v3.0

Scroll down for code samples, example requests and responses. Select a language for code samples from the tabs above or the mobile navigation menu.

Samco Trade API is a set of Rest APIs using which users can build customized applications based on their trading requirements. It facilitates the users of the APIs to login, search symbols, place orders and execute them, view their order status, positions and holdings etc. This documentation provides you with all the necessary details to understand the SAMCO Trade API collection. APIs are compatible with both Javascript and Python.

For any issues or support, please raise ticket to us using the support link and we will be happy to assist you.

For Reference you can download postman collection Click here

For downloading a list of all tradeable scrips across exchanges please Click here This is a CSV file which you can import into your database.

NOTE: To ensure stability and there by provide seamless services to our customers, Samco may set limits on your use of the Trade APIs (for example, limit on the number of requests sent to a specific API) . If you have additional questions regarding the rate limits on APIs, please reach out to us using the support link and we will be happy to assist you.

Supports the list of following index names:

BSE CG	SENSEX	BSE CD	NIFTY50 PR 1x INV
BSE IT	METAL	OILGAS	NIFTY50 PR 2x LEV
BSEIPO	GREENX	POWER	NIFTY50 TR 1x INV
CARBON	BASMTR	CDGS	NIFTY50 TR 2x LEV
BSEFMC	BSE HC	ALLCAP	NIFTY50 TR 2x LEV
REALTY	SMEIPO	DOL30	NIFTY Mid LIQ 15
LRGCAP	MIDSEL	SMLSEL	NIFTY100 LIQ 15
SNXT50	SNSX50	NIFTY 50	NIFTY Quality 30
NIFTY BANK	NIFTY NEXT 50	DOL100	NIFTY MIDCAP 50
NIFTY 100	NIFTY 200	NIFTY 500	NIFTY FIN SERVICE
NIFTY AUTO	NIFTY FMCG	NIFTY IT	NIFTY COMMODITIES
NIFTY MEDIA	NIFTY METAL	NIFTY PHARMA	NIFTY CONSUMPTION
NIFTY PSU BANK	NIFTY PVT BANK	NIFTY REALTY	NIFTY GROWSECT 15
NIFTY CPSE	NIFTY ENERGY	NIFTY INFRA	NIFTY DIV OPPS 50
NIFTY MNC	NIFTY PSE	NIFTY SERV SECTOR	NIFTY MID100 FREE
DOL200	TECK	BSEPSU	NIFTY SML100 FREE
AUTO	BANKEX	INDIA VIX	NIFTY50 VALUE 20

APIs will work intermittently over the weekends/holidays and outside market hours due to maintenance activity. Base URLs:

https://tradeapi.samco.in

Http Request Header

This is the request header which should be included in every api.

Name	Required	Discription
Accept	false	Accept indicates what the format of the response will be.If the user does not provide an accept , by default considered as application/json .Only accept type application/json, / or blank is acceptable.
Content-Type	false	Content-Type refers to the media type or MIME type of the data in an HTTP message, indicating the type of content being sent, by default considered as application/json .Only Content-Type type application/json, / or blank is acceptable.
x-session-token	true	When one hits the login-api, it receives a session token in response. The same token is used here for validation for all api.

Http Response Code

The HTTP response code indicates the success or failure of an HTTP request. Below is a list

Name	Meaning	Description
200	OK	API response received successfully
400	Bad Request	Input validation Failed. Check the validation errors in response object.
406	Not Acceptable	Client's request headers unacceptable. Server can't provide desired response.
415	Unsupported Media Type	Unsupported media type in request.Server cannot process the content.
429	Too Many Requests	rate limiting
500	Internal Server Error	Server Error

Trade Limits

Rate Limits - March 2024

Our Samco Trade APIs are set with defined rate limits, which are based on the IP address. If these limits are exceeded, a "429 - Too Many Requests" error may occur. We've recently updated our rate limit policy, which involves enhancing the limits for specific Samco APIs.

Updated list of our API request limits and time limits:

TradeAPI - Rate Limit Configuration
API Name	Requests URL	Session	IP
User Login	/login	5	200
Personal Index	/indexData	3	20
Market Depth	/marketDepth	3	20
Add GTT	/gttoco/addGtt	3	20
Modify GTT	/gttoco/modifyGtt	3	20
Delete GTT	/gttoco/deleteGtt	3	20
Add OCO	/gttoco/addOco	3	20
Modify OCO	/gttoco/modifyOco	3	20
Delete OCO	/gttoco/deleteOco	3	20
List GTT OCO	/gttoco/listGttOco	3	20
Span Margin	/spanMargin	3	20
Get Quote	/quote/getQuote	10	500
Index Quote	/quote/indexQuote	10	500
Multi Quote	/quote/multiQuote	10	500
Search Equity & Derivative	/eqDervSearch/search	5	500
Option Chain	/option/optionChain	1	20
Future Chain	/future/futureChain	1	20
User Limits	/limit/getLimits	2	200
Place Order	/order/placeOrder	200	200
Place BO Order	/order/placeOrderBO	200	200
Place CO Order	/order/placeOrderCO	200	200
Get Order Status	/order/getOrderStatus	100	200
Order Book	/order/orderBook	100	200
TriggerOrders	/order/getTriggerOrders	20	200
Modify Order	/order/modifyOrder	100	200
Cancel BO Order	/order/exitBO	5	200
Cancel CO Order	/order/exitCO	5	200
Cancel Order	/order/cancelOrder	100	200
Trade Book	/trade/tradeBook	5	20
User Positions	/position/getPositions	5	200
Position Conversion	/position/convertPosition	5	200
Position Square Off	/position/squareOff	20	200
User Holdings	/holding/getHoldings	2	200
Intraday candle data	/intraday/candleData	5	20
Index IntraDay candle data	/intraday/indexCandleData	5	20
Historical candle data	/history/candleData	5	20
Index Historical CandleData	/history/indexCandleData	5	20

Body parameter


requestBody={
  "userId": "DV99999",
  "password": "abc1234",
  "yob": "1975"
}

Code samples

var headers = {
  'Content-Type' : 'application/json',
  'Accept' : 'application/json'
};

$.ajax({
  url : 'https://tradeapi.samco.in/login',
  method : 'post',
  data : JSON.stringify(requestBody),
  headers : headers,
  success : function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})


import requests

headers = {
  'Content-Type' : 'application/json',
  'Accept' : 'application/json'
}

r = requests.post('https://tradeapi.samco.in/login'
, data=json.dumps(requestBody)
, headers = headers)

print r.json()

POST /login

The Trade APIs allow the user authentication using the Login API. A valid SAMCO Trading Account and subscription to Trade API Services is a pre-requisite for successful authentication. For Example, if you are going to use 3 users for Trading using APIs, all the 3 users will have to open a SAMCO Trading Account and will have to subscribe to SAMCO Trade API Services.

Name	Type	Required	Description
userId	string	true	The client Code provided to you by SAMCO after opening an account.
password	string	true	If user has set password using any of the SAMCO Trading platform i.e. Stocknote Mobile App, Stocknote Web or Stockbasket, then use the password as set. Or else, use the password provided in the welcome email sent to you at the time of account opening.
yob	string	false	Your year of birth.

Example responses

200 Response

{
    "serverTime": "04/04/24 11:06:17",
    "msgId": "4d54c81c-2c57-4049-8683-af0ed3e307d8",
    "status": "Success",
    "statusMessage": "Login session token generated successfully",
    "sessionToken": "e0317d9c9d4749a0706e3994c80653bc",
    "accountID": "RMXXXX3",
    "accountName": "MXXXXXXD XXXH",
    "exchangeList": ["BFO","BSE","CDS","MCX","NSE","NFO"],
    "orderTypeList": ["MKT","L","SL","SL-M"],
    "productList": ["MIS","CNC","NRML","CO","BO"]
}

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'.
statusMessage	string	A message describing the result of the API call.
sessionToken	string	Session token that should be used with API request is given in the response. It is used as an authenticator. A session token is valid for 24 hours or until a new login request is given, where you a new session token will be generated and the previous one will get expired.
accountID	string	Same as Client Code for SAMCO Trading Account, is unique and used for identification of user.
accountName	string	Users full name as registered with Samco Trading Account.
exchangeList	[string]	List of exchanges enabled for trading for the user.
orderTypeList	[string]	List of order types enabled for trading for the user.The list can be from of the following, MKT - Market Order,L- Limit Order,SL - Stop Loss Limit,SL-M - Stop loss market.
productList	[string]	List of product types enabled for the user . It can be CNC (Cash and Carry),BO (Bracket Order),CO (Cover Order),NRML (Normal),MIS (Intraday).

Personal Index

Index Data

GET /indexData

The Index Data API shows the user's personal index. It shows the overall profit and loss of all the trades done by the user.

Code samples


var headers = {
'Accept': 'application/json',
'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

$.ajax({
  url: 'https://tradeapi.samco.in/indexData',
  method: 'Get',
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})


import requests
import json

headers = {
'Accept': 'application/json',
'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'

}

r = requests.get('https://tradeapi.samco.in/indexData'
, headers = headers)

print (r.json())

Parameters

No parameters are required to use this API.

Sample Response

200 Response

{
    "serverTime": "04/04/24 11:22:12",
    "msgId": "2164268d-d38b-490e-bbb2-d3cedda3a907",
    "status": "Success",
    "statusMessage": "Index Data retrieved successfully",
    "indexData": {
        "indexName": "MXXXXXXD IXXXx",
        "networth": "209.52",
        "indexData": {
            "index": "4.04",
            "indexChange": "0.04",
            "indexChangePercentage": "1.04",
            "latestTime": "2024-04-04 11:21:00",
            "networthChange": "2.15",
            "networthChangePercentage": "1.04",
            "fundReceipt": "0.00"
        }
    }
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'.
statusMessage	string	A message describing the result of the API call.
indexDataDetails	Object	User index data details
indexName	string	Client Personal Index.
networth	string	Client's total worth.
indexData	Object	User index data details
Index	string	The latest calculated value of the index.
IndexChange	string	The variance between yesterday's and today's index values.
IndexChangePercentage	string	The percentage change in index value from yesterday to today.
latestTime	string	Timestamp indicating the latest update of the index value.
networthChange	string	The variance between yesterday's and today's net worth values.
networthChangePercentage	string	The percentage change in net worth value from yesterday to today.
fundReceipt	string	Today's payment amount: the sum received or transferred to fund.

Market Depth

POST /marketDepth

Body parameter


requestBody={
  "exchange" : "BFO",
  "symbolName" : "BANKEX2450656000CE"
}

Code samples


var headers = {
  'Content-Type' : 'application/json',
  'Accept' : 'application/json',
  'x-session-token' : 'c5c81c20f0fe81ceb45f93d3621d0938',
}

$.ajax({
   url : 'https://tradeapi.samco.in/marketDepth',
   method : 'POST',
   data : JSON.stringify(requestBody),
   headers : headers,
   success : function(data) {
      console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})


import requests
import json

headers = {
  'Content-Type' : 'application/json',
  'Accept' : 'application/json',
  'x-session-token' : 'c5c81c20f0fe81ceb45f93d3621d0938',
}
r = requests.post('https://tradeapi.samco.in/marketDepth'
, data=json.dumps(requestBody)
, headers = headers)

print (r.json())

Example responses

200 Response

{
    "serverTime": "04/04/24 11:57:24",
    "msgId": "a1454ad2-dc44-4299-8907-faa751b750cd",
    "status": "Success",
    "statusMessage": "Market depth data retrieved successfully",
    "MarketDepthDetails": {
        "marketDepth": {
            "tradingSymbol": "BANKEX2450656000CE",
            "vega": "0.00",
            "theta": "-0.00",
            "gamma": "0.0000",
            "symbol": "870393_BFO",
            "tBuyQty": "0",
            "iv": "1.79",
            "tSellQty": "0",
            "bestFiveAsk": [
                {
                    "askNumber": "0",
                    "askSize": "0",
                    "askPrice": "0.00"
                },
                {
                    "askNumber": "0",
                    "askSize": "0",
                    "askPrice": "0.00"
                },
                {
                    "askNumber": "0",
                    "askSize": "0",
                    "askPrice": "0.00"
                },
                {
                    "askNumber": "0",
                    "askSize": "0",
                    "askPrice": "0.00"
                },
                {
                    "askNumber": "0",
                    "askSize": "0",
                    "askPrice": "0.00"
                }
            ],
            "bestFiveBid": [
                {
                    "bidSize": "0",
                    "bidNumber": "0",
                    "bidPrice": "0.00"
                },
                {
                    "bidSize": "0",
                    "bidNumber": "0",
                    "bidPrice": "0.00"
                },
                {
                    "bidSize": "0",
                    "bidNumber": "0",
                    "bidPrice": "0.00"
                },
                {
                    "bidSize": "0",
                    "bidNumber": "0",
                    "bidPrice": "0.00"
                },
                {
                    "bidSize": "0",
                    "bidNumber": "0",
                    "bidPrice": "0.00"
                }
            ],
            "delta": "0.00",
            "exc": "BFO"
        }
    }
}

Parameters

Name	Type	Required	Description
exchange	string	false	Name of the exchange.Valid exchanges values (BSE/NSE/NFO/BFO/MCX/CDS/MFO).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
symbolName	string	true	Symbol name of the scrip.For Equity enter SymbolName of the scrip & For Derivatives enter TradingSymbol of the scrip

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'.
statusMessage	string	A message describing the result of the API call.
marketDepth	Object	Obtain a list providing Market Depth details.
tradingSymbol	string	Symbol for trading the scrip.
vega	string	The value of an options contract typically increases.
theta	string	The rate of price change in an options contract relative to its remaining time until expiration.
gamma	string	Gamma represents a key factor in option chain calculations.
symbol	string	The actual name of the symbol for the scrip.
tBuyQty	string	Total quantity of BUY transaction.
iv	string	Implied Volatility is how much experts think a stock will change.
tSellQty	string	The overall quantity of SELL transactions.
bestFiveAsk	Object	Obtain a list of Ask values.
bestFiveBid	Object	Obtain a list of Bid Values.
delta	string	The price change of an option relative to the asset's movements.
exc	string	The name of the stock exchange.

GTT Order

A GTT order is a type of limit order that remains active until it is either filled or canceled by the user. This is useful for traders who want to buy or sell a security at a specific price but are not able to monitor the market continuously.

The Trade API mentioned here likely allows traders to interact with a trading platform programmatically, enabling them to place GTT orders without needing to use a graphical user interface (GUI). The API would typically involve sending HTTP requests with specific parameters to a server, which would then execute the order on behalf of the trader.

Add GTT

POST /gttoco/addGtt

GTT (Good Till Triggered) is a feature that allows users to place buy or sell orders of any stock at market or limit price. These orders are executed (triggered) once the market price of the stock reaches your desired price i.e the price you mentioned in the GTT Order. Read More....

In the BFO exchange, only SENSEX and BANKEX trades are allowed.

Body parameter

requestBody={
  "exchange": "BFO",
  "symbolName": "SENSEX502441823950PE",
  "transactionType": "BUY",
  "quantity": "1",
  "productType": "NRML",
  "orderType": "L",
  "triggerPrice": "12",
  "limitPrice": "14",
  "marketProtection": ""
}

Code samples


var headers = {
  'Content-Type' : 'application/json',
  'Accept' : 'application/json',
  'x-session-token' : 'c5c81c20f0fe81ceb45f93d3621d0938',
}

$.ajax({
  url: 'https://tradeapi.samco.in/gttoco/addGtt',
  method: 'post',
  data : JSON.stringify(requestBody),
  headers : headers,
  success : function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})


import requests
import json

headers = {
  'Content-Type' : 'application/json',
  'Accept' : 'application/json',
  'x-session-token' : 'c5c81c20f0fe81ceb45f93d3621d0938',
}

r = requests.post('https://tradeapi.samco.in/gttoco/addGtt'
, data=json.dumps(requestBody)
, headers = headers)

print r.json()

Parameters

Name	Type	Required	Description
exchange	string	true	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ BFO/ MCX/ CDS/ MFO).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO,BFO,CDS,MFO and MCX, exchange is mandatory.
symbolName	string	true	Symbol name of the scrip.For Equity enter SymbolName of the scrip & For Derivatives enter TradingSymbol of the scrip
transactionType	string	true	Determines whether the order is a buy or sell transaction.
quantity	string	true	Defines the number of units or shares of the asset to be bought or sold.
productType	string	true	Product Type of the order. It can be CNC (Cash and Carry)NRML (Normal).The valid product type for F&O (Futures and Options) is NRML
orderType	string	true	Type of order user has placed . It can be one of the following, MKT - Market Order,L- Limit Order.
triggerPrice	string	true	This represents the market-entry price level for the placed order.
limitPrice	string	true	Limit price is a required field for L - Limit orders.This is the price at which the order is executed in the market.
marketProtection	string	true	MarketProtection is a required field for market orders. By default, MarketProtection is set to 3% to protect the order from potential market losses.

Example responses

200 Response

{
    "serverTime": "04/04/24 12:32:34",
    "msgId": "ab50b682-3642-443b-8218-c5fded443076",
    "status": "Success",
    "statusMessage": "GTT CREATED",
    "gttSummaryId": "670185",
    "orderDetails": {
        "productType": "NRML",
        "orderType": "L",
        "triggerPrice": "12",
        "marketProtection": "",
        "transactionType": "BUY",
        "symbol": "860822_BFO",
        "symbolName": "SENSEX502441823950PE",
        "createdAt": "2024-04-04 12:32:34"
    }
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'
statusMessage	string	A message describing the result of the API call.
gttSummaryId	string	gttSummaryId uniquely identifies GTT order, essential for modifying, retrieving status, and deleting.
productType	string	The product type of the order.
orderType	string	The type of order.
triggerPrice	string	The trigger price for the order.
marketProtection	string	The market protection percentage for the order.
transactionType	string	The transaction type for the order.
symbol	string	The actual name of the symbol for the scrip.
symbolName	string	The name of the symbol representing the scrip.
createdAt	string	Timestamp marking the addition of the GTT order.

Modify GTT

PUT /gttoco/modifyGtt

Modifying a GTT (Good Till Triggered) order allows investors to adjust the parameters of their existing GTT orders. This can include changing the trigger price, altering the quantity of the order, productType, limitPrice, marketProtection or modifying the order type.

Body parameter

requestBody={
      "exchange": "NSE",
      "symbolName": "IDEA",
      "transactionType": "BUY",
      "quantity": 20,
      "productType": "CNC",
      "orderType": "L",
      "triggerPrice": 13.10,
      "limitPrice": 13.05,
      "marketProtection": "",
      "gttSummaryId" : 136042
}

Code samples


var headers = {
  'Content-Type' : 'application/json',
  'Accept' : 'application/json',
  'x-session-token' : 'c5c81c20f0fe81ceb45f93d3621d0938',
}

$.ajax({
  url : 'https://tradeapi.samco.in/gttoco/modifyGtt',
  method : 'put',
  data : JSON.stringify(requestBody),
  headers : headers,
  success : function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})


import requests
import json

headers = {
  'Content-Type' : 'application/json',
  'Accept' : 'application/json',
  'x-session-token' : 'c5c81c20f0fe81ceb45f93d3621d0938',
}

r = requests.put('https://tradeapi.samco.in/gttoco/modifyGtt'
, data=json.dumps(requestBody)
, headers = headers)

print (r.json())

Parameters

Name	Type	Required	Description
exchange	string	true	The valid exchange will remain the same as it was at the time of creating the GTT. We cannot modify the exchange.
symbolName	string	true	The symbol name will also remain the same as it was at the time of creating the GTT. We cannot modify the symbol name.
transactionType	string	true	Determines whether the order is a buy or sell transaction.
quantity	number	true	Defines the number of units or shares of the asset to be bought or sold.
productType	string	true	Product Type of the order. It can be CNC (Cash and Carry)NRML (Normal)
orderType	string	true	Type of order user has placed . It can be one of the following, MKT - Market Order,L- Limit Order.
triggerPrice	number	true	This represents the market-entry price level for the placed order.
limitPrice	number	true	This is the price at which the order is executed in the market.
marketProtection	string	true	MarketProtection is a required field for market orders. By default, MarketProtection is set to 3% to protect the order from potential market losses.
gttSummaryId	number	true	Enter the gttSummaryId of the GTT order you want to modify here.

Example responses

200 Response

{
    "serverTime": "28/02/24 12:47:38",
    "status": "Success",
    "msgId": "242c7fa5-a6f7-438f-859b-a4b5ced39ce5",
    "gttSummaryId": "136045",
    "statusMessage": "GTT order Modified",
    "orderDetails": {
        "productType": "CNC",
        "orderType": "L",
        "triggerPrice": "13.10",
        "marketProtection": "",
        "transactionType": "BUY",
        "limitPrice": "13.05",
        "symbol": "14366_NSE",
        "symbolName": "IDEA",
        "quantity": "20",
    }
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'
statusMessage	string	A message describing the result of the API call.
gttSummaryId	string	After the order is modified, a new gttSummaryId is generated. For any further operation, this gttSummaryId will be valid for this order and the gttSummaryId becomes invalid.
productType	string	The product type of the order.
orderType	string	The type of order.
triggerPrice	string	The trigger price for the order.
marketProtection	string	The market protection percentage for the order.
transactionType	string	The transaction type for the order.
limitPrice	string	This is the price at which the order is executed in the market.
symbol	string	The actual name of the symbol for the scrip.
symbolName	string	The name of the symbol representing the scrip.
quantity	string	Defines the number of units or shares of the asset to be bought or sold.

Delete GTT

DELETE /gttoco/deleteGtt

Deleting a GTT order cancels it before execution, removing it from the exchange's order book and preventing future execution. Once GTT is triggered, deletion is not possible.

Body parameter


requestBody={
  "gttSummaryId" : 136045
}

Code samples


var headers = {
  'Content-Type' : 'application/json',
  'Accept' : 'application/json',
  'x-session-token' : 'c5c81c20f0fe81ceb45f93d3621d0938',
}

$.ajax({
  url : 'https://tradeapi.samco.in/gttoco/deleteGtt',
  method : 'delete',
  data : JSON.stringify(requestBody),
  headers : headers,
  success : function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})


import requests
import json

headers = {
  'Content-Type' : 'application/json',
  'Accept' : 'application/json',
  'x-session-token' : 'c5c81c20f0fe81ceb45f93d3621d0938',
}

r = requests.delete('https://tradeapi.samco.in/gttoco/deleteGtt'
, data=json.dumps(requestBody)
, headers = headers)

print r.json()

Parameters

Name	Type	Required	Description
gttSummaryId	number	true	Enter the gttSummaryId of the GTT order you want to delete here.

Example responses

200 Response

{
    "serverTime": "28/02/24 12:49:19",
    "status": "Success",
    "msgId": "a62afb04-84a5-4d3d-ba5b-3299cce4fd77",
    "gttSummaryId": "136045",
    "statusMessage": "GTT order Deleted",
    "orderDetails": {
        "userId": "RM1001"
    }
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'
statusMessage	string	A message describing the result of the API call.
gttSummaryId	string	gttSummaryId of the order which is deleted.
userId	string	User ID of the user who deleted the order.

Add OCO

POST /gttoco/addOco

Add OCO refers to the functionality of adding an OCO (One-Cancels-the-Other) condition to a GTT (Good Till Triggered) order. With this feature, investors can set up two separate exit conditions for a single position. If one condition is triggered and the corresponding order is executed, the other order is automatically canceled, hence the "one-cancels-the-other" concept.

Here’s how it works?

Let’s say you are holding a stock in your portfolio and you have kept a target and stoploss in mind for exiting this stock.
You can place a GTT OCO order and Enter your target trigger and stoploss trigger along with respective order prices. Once you’ve entered your target and stoploss prices, our system will start monitoring the market.
If the price of your stock reaches your target price, our system will automatically place a sell order with target price for you. In this scenario, your stoploss trigger will get canceled automatically.
If the price of your stock reaches your stoploss price, our system will automatically place a sell order with stoploss price for you. In this scenario, your target trigger will get canceled automatically. Read More....

In the BFO exchange, only SENSEX and BANKEX trades are allowed.

Body parameter

requestBody={
    "exchange": "NSE",
    "symbolName": "IDEA",
    "transactionType": "SELL",
    "quantity": "5",
    "productType": "CNC",
    "orderType": "L",
    "targetTriggerPrice": "13.5",
    "targetLimitPrice": "13.5",
    "stoplossTriggerPrice": "10.5",
    "stoplossLimitPrice": "10.5",
    "marketProtection": ""
}

Code samples


var headers = {
  'Content-Type' : 'application/json',
  'Accept' : 'application/json',
  'x-session-token' : 'c5c81c20f0fe81ceb45f93d3621d0938'
}

$.ajax({
  url: 'https://tradeapi.samco.in/gttoco/addOco',
  method: 'post',
  data : JSON.stringify(requestBody),
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
import json

headers = {
    'Content-Type' : 'application/json',
    'Accept' : 'application/json',
    'x-session-token' : 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.post('https://tradeapi.samco.in/gttoco/addOco'
, data=json.dumps(requestBody)
, headers = headers)

print r.json()

Parameters

Name	Type	Required	Description
exchange	string	true	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ BFO/ MFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, BFO, MFO, CDS and MCX, exchange is mandatory.
symbolName	string	true	Symbol name of the scrip.For Equity enter SymbolName of the scrip & For Derivatives enter TradingSymbol of the scrip
transactionType	string	true	Determines whether the order is a buy or sell transaction. EQ delivery buy order not allowed in the Gtt.
quantity	string	true	Defines the number of units or shares of the asset to be bought or sold.
productType	string	true	Product Type of the order. It can be CNC (Cash and Carry)NRML (Normal)
orderType	string	true	Type of order user has placed . It can be one of the following, MKT - Market Order,L- Limit Order.
targetTriggerPrice	string	true	The targetTriggerPrice at which the order will enter the market.
targetLimitPrice	string	true	targetLimitPrice is a required field for limit orders. The targetLimitPrice at which the order will be executed on the exchange.
stoplossTriggerPrice	string	false	The stoplossTriggerPrice at which the order will enter the market.
stoplossLimitPrice	string	true	stoplossLimitPrice is a required field for limit orders. The stoplossLimitPrice at which the order will be executed on the exchange.
marketProtection	string	true	MarketProtection is a required field for market orders. By default, MarketProtection is set to 3% to protect the order from potential market losses.

Example responses

200 Response

{
    "serverTime": "04/04/24 13:21:04",
    "msgId": "474288ae-dc9c-4ea3-82ee-9f6c9ba9b0d9",
    "status": "Success",
    "statusMessage": "GTT CREATED",
    "gttSummaryId": "670745",
    "orderDetails": {
        "transactionType": "SELL",
        "symbol": "14366_NSE",
        "symbolName": "IDEA",
        "productType": "CNC",
        "orderType": "L",
        "target": {
            "quantity": "5",
            "triggerPrice": "13.5",
            "limitPrice": "13.5",
            "marketProtection": "",
            "type": "TARGET",
            "triggerId": "932060"
        },
        "stopLoss": {
            "quantity": "5",
            "triggerPrice": "10.5",
            "limitPrice": "10.5",
            "marketProtection": "",
            "type": "STOPLOSS",
            "triggerId": "932065"
        }
    }
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'
statusMessage	string	A message describing the result of the API call.
gttSummaryId	string	gttSummaryId uniquely identifies GTT order, essential for modifying, retrieving status, and deleting.
transactionType	string	Determines whether the order is a buy or sell transaction.
symbol	string	The actual name of the symbol for the scrip.
symbolName	string	The name of the symbol representing the scrip.
productType	string	The product type of the order.
orderType	string	The type of order.
target	object	An object containing details about the target order.
stopLoss	object	An object containing details about the stop loss order.

Modify OCO

PUT /gttoco/modifyOco

Modifying a GTT OCO (Good Till Triggered, One-Cancels-the-Other) order involves adjusting the parameters of an existing GTT OCO order. This can include changing the trigger prices, adjusting the quantity of the order, or modifying the order types.

When modifying a GTT OCO order, investors can make changes to both legs of the OCO order, ensuring that the exit strategies remain aligned with their trading objectives and market conditions. For example, if market conditions change and the investor wants to adjust their profit target or stop-loss levels, they can modify the trigger prices accordingly.

Body parameter

requestBody={
    "exchange": "NSE",
    "symbolName": "IDEA",
    "transactionType": "SELL",
    "quantity": "25",
    "productType": "CNC",
    "orderType": "L",
    "targetTriggerPrice": "13.5",
    "targetLimitPrice": "13.5",
    "stoplossTriggerPrice": "10.5",
    "stoplossLimitPrice": "10.5",
    "marketProtection": "",
    "gttSummaryId" : 670745
}

Code samples

var headers = {
    'Content-Type' : 'application/json',
    'Accept' : 'application/json',
    'x-session-token' : 'c5c81c20f0fe81ceb45f93d3621d0938'
};

$.ajax({
  url: 'https://tradeapi.samco.in/gttoco/modifyOco',
  method: 'put',
  data : JSON.stringify(requestBody),
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
import json

headers = {
    'Content-Type' : 'application/json',
    'Accept' : 'application/json',
    'x-session-token' : 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.put('https://tradeapi.samco.in/gttoco/modifyOco'
, data=json.dumps(requestBody)
, headers = headers)

print (r.json())

Parameters

Name	Type	Required	Description
exchange	string	true	The valid exchange will remain the same as it was at the time of creating the GTT OCO . We cannot modify the exchange.
symbolName	string	true	The symbol name will also remain the same as it was at the time of creating the GTT OCO. We cannot modify the symbol name.
transactionType	string	true	Determines whether the order is a buy or sell transaction.
quantity	string	true	Defines the number of units or shares of the asset to be bought or sold.
productType	string	true	Product Type of the order. It can be CNC (Cash and Carry)NRML (Normal)
orderType	string	true	Type of order user has placed . It can be one of the following, MKT - Market Order,L- Limit Order.
targetTriggerPrice	string	true	The targetTriggerPrice at which the order will enter the market.
targetLimitPrice	string	true	targetLimitPrice is a required field for limit orders. The targetLimitPrice at which the order will be executed on the exchange.
stoplossTriggerPrice	string	true	The stoplossTriggerPrice at which the order will enter the market.
stoplossLimitPrice	string	true	stoplossLimitPrice is a required field for limit orders. The stoplossLimitPrice at which the order will be executed on the exchange.
marketProtection	string	true	MarketProtection is a required field for market orders. By default, MarketProtection is set to 3% to protect the order from potential market losses.
gttSummaryId	number	true	Enter the gttSummaryId of the GTT OCO order you want to modify here.

Example responses

200 Response

{
    "serverTime": "04/04/24 13:53:23",
    "msgId": "432b12e6-6acc-4b38-98b3-3940e09d0c26",
    "status": "Success",
    "statusMessage": "GTT MODIFIED",
    "gttSummaryId": "671170",
    "orderDetails": {
        "transactionType": "SELL",
        "orderType": "L",
        "symbol": "14366_NSE",
        "symbolName": "IDEA",
        "productType": "CNC",
        "target": {
            "limitPrice": "13.5",
            "triggerId": "932815",
            "triggerPrice": "13.5",
            "type": "TARGET",
            "quantity": "25",
            "marketProtection": ""
        },
        "stopLoss": {
            "limitPrice": "10.5",
            "triggerId": "932820",
            "triggerPrice": "10.5",
            "type": "STOPLOSS",
            "quantity": "25",
            "marketProtection": ""
        }
    }
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'
statusMessage	string	A message describing the result of the API call.
gttSummaryId	string	After the order is modified, a new gttSummaryId is generated. For any further operation, this gttSummaryId will be valid for this order and the gttSummaryId becomes invalid.
transactionType	string	transaction type describes whether it involves buying or selling.
orderType	string	The type of order.
symbol	string	The actual name of the symbol for the scrip.
symbolName	string	The name of the symbol representing the scrip.
productType	string	The product type of the order.
target	object	An object containing details about the target order.
stopLoss	object	An object containing details about the stop loss order.

Delete OCO

DELETE /gttoco/deleteOco

Deleting an OCO (One-Cancels-the-Other) order involves canceling both legs of the order simultaneously. In an OCO order, when one part of the order is executed, the other part is automatically canceled. However, if the investor decides to delete the entire OCO order before either part is executed, they can do so using the delete OCO API.

Body parameter


requestBody={
    "gttSummaryId" : 136045
}

Code samples

var headers = {
    'Content-Type' : 'application/json',
    'Accept' : 'application/json',
    'x-session-token' : 'c5c81c20f0fe81ceb45f93d3621d0938'
}

$.ajax({
  url: 'https://tradeapi.samco.in/gttoco/deleteOco',
  method: 'delete',
  data : JSON.stringify(requestBody),
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
import json

headers = {
    'Content-Type' : 'application/json',
    'Accept' : 'application/json',
    'x-session-token' : 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.delete('https://tradeapi.samco.in/gttoco/deleteOco'
, data=json.dumps(requestBody)
, headers = headers)

print (r.json())

Parameters

Name	Type	Required	Description
gttSummaryId	number	true	Enter the gttSummaryId of the GTT order you want to delete here.

Example responses

200 Response

{
    "serverTime": "28/02/24 12:49:19",
    "status": "Success",
    "msgId": "a62afb04-84a5-4d3d-ba5b-3299cce4fd77",
    "gttSummaryId": "136045",
    "statusMessage": "GTT OCO order Deleted",
    "orderDetails": {
        "userId": "RM1001"
    }
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'
statusMessage	string	A message describing the result of the API call.
gttSummaryId	string	gttSummaryId of the order which is deleted.
userId	string	User ID of the user who deleted the order.

List GTT OCO

GET /gttoco/listGttOco

Using the list OCO, we can retrieve the list of active GTT OCO, triggered GTT OCO, and expired GTT OCO.

Code samples


var headers = {
  'Accept':'application/json',
  'x-session-token':'115aead43798e35cef8308c15cc79c7a'

};

$.ajax({
  url: 'https://tradeapi.samco.in/gttoco/listGttOco?listType=active',
  method: 'get',
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token':'115aead43798e35cef8308c15cc79c7a'
}

r = requests.get('https://tradeapi.samco.in/gttoco/listGttOco', params={
  'listType': 'active'
}
, headers = headers)

print (r.json())

Parameters

Name	Type	Required	Description
listType	string	true	Type of list. valid type is (active / triggered / expired). If the user does not provide a listType, by default considered as active.

Example responses

200 Response

{
    "serverTime": "04/04/24 14:18:54",
    "msgId": "ec67dc5b-d626-4e16-a3eb-461ac37bb93b",
    "status": "Success",
    "statusMessage": "List of GTT / OCO orders received.",
    "orderDetails": [
        {
            "summary": {
                "id": 136027,
                "userId": "RM1001",
                "symbol": "14366_NSE",
                "symbolName": "IDEA",
                "orderType": "L",
                "productType": "CNC",
                "gttType": "SINGLE",
                "validTill": "FOREVER",
                "createdAt": "2024-02-28 17:52:27",
                "deletedAt": "",
                "gttSummaryId": "136027",
                "isExpired": false,
            },
            "triggers": {
                "gtt": {
                    "status": "",
                    "triggeredAt": "",
                    "triggerId": "172714",
                    "gttId": "172714",
                    "quantity": "1",
                    "limitPrice": "13.25",
                    "marketProtection": "",
                    "ltpAtCreation": "16.30",
                    "triggerPrice": "13.50",
                    "transactionType": "BUY",
                    "rejectReason": "",
                    "orderNumber": ""
                }
            }
        }
    ]
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'
statusMessage	string	A message describing the result of the API call.
summary	object	Summary data for GTT orders.
gtt	object	GTT order details availbale for GTT orders.
target	object	Target details availbale for OCO orders.
stopLoss	oject	Stoploss details availbale for OCO orders.

Span Margin

Body parameter

requestBody={
    "request":[
        {
            "exchange":"NFO",
            "tradingSymbol":"TECHM23DEC1220CE",
            "qty":"600"
        },
        {
            "exchange":"NFO",
            "tradingSymbol":"TECHM23DECFUT",
            "qty":"175"
        }
    ]
}

Code samples

var headers = {
    'Content-Type' : 'application/json',
    'Accept' : 'application/json',
    'x-session-token' : 'c5c81c20f0fe81ceb45f93d3621d0938'
};

$.ajax({
  url: 'https://tradeapi.samco.in/spanMargin',
  method: 'post',
  data: JSON.stringify(requestBody),
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
import json

headers = {
    'Content-Type' : 'application/json',
    'Accept' : 'application/json',
    'x-session-token' : 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.post('https://tradeapi.samco.in/spanMargin'
, data=json.dumps(requestBody)
, headers = headers)

print (r.json())

POST /spanMargin

Parameters

Name	Type	Required	Description
exchange	string	true	Name of the exchange
tradingSymbol	string	true	Trading Symbol of the scrip.
qty	string	true	Quantity asked for margin.

Example responses

200 Response

{
    "serverTime": "02/02/24 06:36:39",
    "msgId": "a62b91a3-2b74-450a-85a2-8e7a4fbb4cca",
    "status": "Success",
    "statusMessage": "Span margin calculated",
    "spanDetails": {
        "totalRequirement": "312258.00",
        "spanRequirement": "192258.00",
        "exposureMargin": "120000.00",
        "spreadBenefit": "00.00"
    }
}

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'
statusMessage	string	A message describing the result of the API call.
totalRequirement	string	This is the total amount of margin required for a particular portfolio of futures and options positions. It includes the SPAN requirement, exposure margin, and any additional margin that may be required by the exchange.
spanRequirement	string	This is the margin requirement calculated using the SPAN algorithm, which is a risk-based margining system. The SPAN requirement takes into account factors such as price volatility, correlation between different positions, and the overall risk of the portfolio.
exposureMargin	string	Exposure margin is an additional margin that may be required by the exchange to cover potential losses beyond those accounted for by the SPAN requirement. It provides a buffer against adverse market movements and helps ensure that traders maintain sufficient margin to cover their positions.
spreadBenefit	string	Spread benefit refers to a reduction in margin requirements that may be applied when certain offsetting positions are held in the same account. This reduction reflects the reduced risk associated with offsetting positions and encourages traders to engage in spread trading strategies.

Quote

Index Quote

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/quote/indexQuote?indexName=Sensex',
  method: 'get',
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})


import requests
import json

headers = {
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.get('https://tradeapi.samco.in/quote/indexQuote', params={
  'indexName': 'Sensex'
}, headers = headers)

print r.json()

GET /quote/indexQuote

Getting Index Quote details for a specific Indicies. This helps user with market picture of an specific Index Details.

Parameters

Name	Type	Required	Description
indexName	string	true	Index name of the scrip.

Example responses

200 Response

{
    "serverTime": "04/04/24 14:34:13",
    "msgId": "13f6cb1e-8c31-4c5c-a15b-df7b27ac15a5",
    "status": "Success",
    "statusMessage": "Index Quote details retrieved successfully",
    "indexDetails": [
        {
            "indexName": "SENSEX",
            "listingId": "-101",
            "lastTradedTime": "2024-04-04 14:34:12.0",
            "spotPrice": 74344.02,
            "changePercentage": 0.63,
            "averagePrice": 0,
            "openValue": 74413.82,
            "highValue": 74501.73,
            "lowValue": 73485.12,
            "closeValue": 73876.82,
            "totalBuyQuantity": 0,
            "totalSellQuantity": 0,
            "totalTradedValue": 0,
            "totalTradedVolume": 0,
            "change": 467.2
        }
    ]
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'
statusMessage	string	A message describing the result of the API call.
indexName	string	Index Name of the indices.
listingId	string	Identifier assigned to the scrip by exchange in the format <>_<>
lastTradedTime	string	Time of the last transaction
spotPrice	string	Spot price. Applicable in case of Futures and Options
changePercentage	string	Percentage of change between the current value and the previous day's market close
averagePrice	string	average price of a market snapshot
openValue	string	Opening price of a market snapshot
highValue	string	High value of market snapshot
lowValue	string	Low value of market snapshot
closeValue	string	Close value of market snapshot
totalBuyQuantity	string	Total quantity of BUY transaction
totalSellQuantity	string	Total quantity of SELL transaction
totalTradedValue	string	Value of total trade made for the scrip
totalTradedVolume	string	Total volume of trading done
change	string	Change value is the difference between the current value and the previous day's market close.

Get Quote

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/quote/getQuote?symbolName=ASIANPAINT24APR2760PE&exchange=NFO',
  method: 'get',
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.get('https://tradeapi.samco.in/quote/getQuote', params={
  'symbolName': 'ASIANPAINT24APR2760PE','exchange':'NFO'
}, headers = headers)

print r.json()

GET /quote/getQuote

Get market depth details for a specific equity scrip including but not limited to values like last trade price, previous close price, change value, change percentage, bids/asks, upper and lower circuit limits etc. This helps user with market picture of an equity scrip using which he will be able to place an order.

Parameters

Name	Type	Required	Description
exchange	string	false	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ BFO/ MCX/ MFO/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, BFO, MFO, CDS and MCX, exchange is mandatory.
symbolName	string	true	Symbol name of the scrip.For Equity enter SymbolName of the scrip & For Derivatives enter TradingSymbol of the scrip

Example responses

200 Response

{
    "serverTime": "04/04/24 15:47:05",
    "msgId": "4568350b-c552-4a53-8981-45241b5d20e7",
    "status": "Success",
    "statusMessage": "Quote details retrieved successfully",
    "quoteDetails": {
        "symbolName": "ASIANPAINT",
        "tradingSymbol": "ASIANPAINT24APR2760PE",
        "exchange": "NFO",
        "lastTradedTime": "04/04/2024 15:29:58",
        "lastTradedPrice": "09.95",
        "previousClose": "14.7",
        "changeValue": "-4.75",
        "changePercentage": "-32.31",
        "lastTradedQuantity": "200",
        "lowerCircuitLimit": "0.05",
        "upperCircuitLimit": "36.45",
        "averagePrice": "11.92",
        "openValue": "13.2",
        "highValue": "18.85",
        "lowValue": "7.65",
        "closeValue": "14.7",
        "totalBuyQuantity": "45200",
        "totalSellQuantity": "29000",
        "totalTradedValue": "31.4211200 (Lacs)",
        "totalTradedVolume": "263600",
        "yearlyHighPrice": "0",
        "yearlyLowPrice": "0",
        "tickSize": "0.05",
        "bestBids": [
            {
                "number": "1",
                "quantity": "200",
                "price": "9.6"
            },
            {
                "number": "2",
                "quantity": "200",
                "price": "9.55"
            },
            {
                "number": "3",
                "quantity": "200",
                "price": "9.5"
            },
            {
                "number": "4",
                "quantity": "200",
                "price": "9.45"
            },
            {
                "number": "5",
                "quantity": "6000",
                "price": "8.35"
            }
        ],
        "bestAsks": [
            {
                "number": "1",
                "quantity": "200",
                "price": "10.2"
            },
            {
                "number": "2",
                "quantity": "200",
                "price": "10.25"
            },
            {
                "number": "3",
                "quantity": "200",
                "price": "10.6"
            },
            {
                "number": "4",
                "quantity": "200",
                "price": "10.65"
            },
            {
                "number": "5",
                "quantity": "200",
                "price": "10.75"
            }
        ],
        "listingId": "73859_NFO",
        "openInterestChange": "-4200",
        "instrument": "OPTSTK",
        "expiryDate": "25 Apr 24",
        "lotQuantity": "200",
        "oIChangePer": "-9.95"
    }
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'
statusMessage	string	A message describing the result of the API call.
symbolName	string	Symbol name of the scrip.
tradingSymbol	string	Trading Symbol of the scrip.
exchange	string	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
companyName	string	Full name of the company
lastTradedTime	string	Time of the last transaction
lastTradedPrice	string	Price at which last transaction / trade is done
previousClose	string	Previous close refers to the prior day's final price of a security when the market officially closes for the day
changeValue	string	Change value is the difference between the current value and the previous day's market close
changePercentage	string	Percentage of change between the current value and the previous day's market close
lastTradedQuantity	string	Quantity of last transaction
lowerCircuitLimit	string	Limit below which a stock price cannot trade on a particular trading day
upperCircuitLimit	string	Limit above which a stock price cannot trade on a particular trading day
averagePrice	string	Average price of the trading
openValue	string	Opening price of a market snapshot
highValue	string	High value of market snapshot
lowValue	string	Low value of market snapshot
closeValue	string	Close value of market snapshot
totalBuyQuantity	string	Total quantity of BUY transaction
totalSellQuantity	string	Total quantity of SELL transaction
totalTradedValue	string	Value of total trade made for the scrip
totalTradedVolume	string	Total volume of trading done
yearlyHighPrice	string	52 week high
yearlyLowPrice	string	52 week low
tickSize	string	The value of a single price tick. Default value is 0.05
openInterest	string	Open interest is the Number of existing contracts held by buyers or sellers for any market for any given day.
bestBids	[object]	Most frequent trading bids for BUY
number	string	Sequence number for Bid/Ask
quantity	string	Quantity asked for trading.
price	string	Price asked for trading.
bestAsks	[object]	Most frequent trading asked for SELL
number	string	Sequence number for Bid/Ask
quantity	string	Quantity asked for trading.
price	string	Price asked for trading.
expiryDate	string	Expiry date of the scrip
spotPrice	string	Spot price. Applicable in case of Futures and Options
instrument	string	Instrument Name.
lotQuantity	string	Lot quantity. Applicable for F & O
listingId	string	Identifier assigned to the scrip by exchange in the format <>_<>
openInterestChange	string	It shows Open interest change in Number of contracts held for market
getoIChangePer	string	It will shows the change % based on Open Interest

Multi Quote

POST /quote/multiQuote

Body parameter


requestBody={
  "NSE":["TCS"],
  "MFO" :["SILVER24APR76250PE"]
}

Code samples


var headers = {
  'Content-Type': 'application/json',
  'Accept': 'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938',
}

$.ajax({
   url: 'https://tradeapi.samco.in/quote/multiQuote',
   method: 'POST',
   data: JSON.stringify(requestBody),
   headers: headers,
   success: function(data) {
      console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})


import requests
import json

headers = {
  'Content-Type': 'application/json',
  'Accept': 'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938',
}

r = requests.post('https://tradeapi.samco.in/quote/multiQuote'
, data=json.dumps(requestBody)
, headers = headers)

print (r.json())

Example responses

200 Response

{
    "serverTime": "05/04/24 10:46:55",
    "msgId": "6dd6d540-33a5-4516-9818-e223370f4846",
    "status": "Success",
    "statusMessage": "Multiquotes data retrieved successfully",
    "multiQuotes": [
        {
            "exchange": "NSE",
            "symbolName": "TCS",
            "tradingSymbol": "TCS-EQ",
            "companyName": "TATA CONSULTANCY SERV LT",
            "isin": "INE467B01029",
            "lotSize": "1",
            "averagePrice": "3840.50",
            "totalTradeVolume": "4311783",
            "symbol": "11536_NSE",
            "lastTradeTime": "28 Mar 2024, 07:11:43 PM",
            "lastTradeQuantity": "1",
            "lastTradePrice": "3876.30",
            "misMultiplier": "4.00",
            "change": "35.40",
            "changePercent": "0.92",
            "open": "3850.10",
            "close": "3876.30",
            "previousClose": "3840.90",
            "low": "3840.50",
            "high": "3915.00",
            "tickSize": "0.05",
            "bidSize": "782",
            "bidPrice": "3876.30",
            "totalTradedValue": "16732176051.06",
            "askSize": "0",
            "askPrice": "0.00",
            "iv": "0.00"
        },
        {
            "exchange": "MCX",
            "symbolName": "SILVER",
            "tradingSymbol": "SILVER24APR76250PE",
            "optionType": "PE",
            "instrumentType": "OPTCOM",
            "companyName": "SILVER",
            "lotSize": "30",
            "strikePrice": "76250.0000",
            "expiry": "24 Apr 24",
            "averagePrice": "0.00",
            "totalTradeVolume": "0",
            "symbol": "256981_MFO",
            "lastTradeTime": "01 Apr 2024, 04:34:41 PM",
            "lastTradeQuantity": "0",
            "lastTradePrice": "0.00",
            "misMultiplier": "100.00",
            "multiplier": "30",
            "openInterest": "0",
            "previousOpenInterest": "0",
            "change": "0.00",
            "changePercent": "0.00",
            "open": "0.00",
            "close": "1656.00",
            "previousClose": "0.00",
            "low": "0.00",
            "high": "0.00",
            "tickSize": "0.5",
            "bidSize": "0",
            "bidPrice": "0.00",
            "totalTradedValue": "0.00",
            "askSize": "0",
            "askPrice": "0.00",
            "delta": "0.00",
            "vega": "0.00",
            "theta": "0.00",
            "gamma": "0.0000",
            "iv": "0.00"
        }
    ]
}

Parameters

Name	Type	Required	Description
BSE	array	false	Assign the array of BSE symbol names to the BSE key.
NSE	array	false	Assign the array of NSE symbol names to the NSE key.
BFO	array	false	Assign the array of trading symbols to the BFO key.
NFO	array	false	Include the NFO trading symbol in the array and assign it to the NFO key.
CDS	array	false	Assign the array of CDS trading symbols to the CDS key.
MCX	array	false	Assign the array of MCX trading symbols to the MCX key.
MFO	array	false	Assign the array of MFO trading symbols to the MFO key.
INDEX	array	false	Assign the array of index names to the INDEX key.

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'
statusMessage	string	A message describing the result of the API call.
multiQuotes	Object	Get list of multiQuote.
exchange	string	Name of the exchange.
symbolName	string	Symbol name of the scrip.
tradingSymbol	string	Trading Symbol of the scrip.
optionType	string	Option Type (PE/CE).
instrumentType	string	Instrument Name.
companyName	string	Full name of the trading company.
isin	string	The standard ISIN representing stocks uniquely at international level. It is same for every exchange.
lotSize	string	Lot size of the symbol to be traded. At the time of placing order, the quantity should be in multiples of Broadlot Qty only.
strikePrice	string	The strike price is the predetermined price at which a put buyer can sell the underlying asset.
expiry	string	Shows expiry date of a trading symbol.
averagePrice	string	Average trading price of the equity or derivative.
totalTradeVolume	string	The total amount of shares or contracts that have been traded.
symbol	string	Actual symbol name of the scrip.
lastTradeTime	string	Last transaction time in milliseconds.
lastTradeQuantity	string	Quantity of last transaction.
lastTradePrice	string	Price at which last transaction / trade is done.
misMultiplier	string	The MIS multiplier indicates how many times a trader can exceed their available funds when purchasing shares."
change	string	Change value is the difference between the current value and the previous day's market close.
changePercent	string	Percentage of change between the current value and the previous day's market close.
open	string	Opening price of a market snapshot.
close	string	Close value of market snapshot.
previousClose	string	Previous close refers to the prior day's final price of security when the market officially closes for the day.
low	string	Low value of market snapshot.
high	string	High value of market snapshot.
tickSize	string	The value of a single price tick. Default value is 0.05 .
bidSize	string	the number of shares investors are trying to buy at a given price
bidPrice	string	The quantity of shares investors seek to purchase at a specified price.
totalTradedValue	string
askSize	string
askPrice	string	Ask Price that seller willing to take for the scrip
iv	string

Search Equity & Derivative

Search Equity scrips

Code samples


var headers = {
  'Accept':'application/json',
  'x-session-token':'115aead43798e35cef8308c15cc79c7a'
};

$.ajax({
  url: 'https://tradeapi.samco.in/eqDervSearch/search?exchange=BFO&searchSymbolName=ZYDUSLIFE24MAYFUT',
  method: 'get',
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})


import requests
import json

headers = {
  'Accept': 'application/json',
  'x-session-token': '115aead43798e35cef8308c15cc79c7a'
}

r = requests.get('https://tradeapi.samco.in/eqDervSearch/search', params={
  'searchSymbolName': 'INFY'
}, headers = headers)

print r.json()

GET /eqDervSearch/search

This API is used to search equity, derivatives and commodity scrips based on user provided search symbol and exchange name.

Parameters

Name	Type	Required	Description
exchange	string	false	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
searchSymbolName	string	true	Trading Symbol of the scrip to be searched

Example responses

200 Response

{
    "serverTime": "05/04/24 16:44:12",
    "msgId": "c0c3fc7c-9000-4d74-8069-6f67009e7e63",
    "status": "Success",
    "statusMessage": "Request successful",
    "searchResults": [
        {
            "exchange": "BFO",
            "tradingSymbol": "ZYDUSLIFE24MAYFUT",
            "quantityInLots": "900",
            "instrument": "FUTSTK"
        }
    ]
}

Response Schema

Status Code 200

Name	Type	Description
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'
statusMessage	string	A message describing the result of the API call.
searchResults	[object]	Scrips Details available for the provided search text.
exchange	string	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
scripDescription	string	scrip description
tradingSymbol	string	Trading Symbol of the scrip.
isin	string	The standard ISIN representing stocks uniquely at international level. It is same for every exchange.
bodLotQuantity	string	none
tickSize	string	The value of a single price tick. Default value is 0.05
instrument	string	Instrument Name.
quantityInLots	string	Lot size of the symbol to be traded. At the time of placing order, the quantity should be in multiples of Broadlot Qty only.

Option

Option Chain

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'115aead43798e35cef8308c15cc79c7a'
};

$.ajax({
  url: 'https://tradeapi.samco.in/option/optionChain?exchange=NFO&searchSymbolName=TCS&strikePrice=3800&optionType=CE&expiryDate=2024-04-25',
  method: 'get',
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})


import requests
import json

headers = {
  'Accept': 'application/json',
  'x-session-token': '115aead43798e35cef8308c15cc79c7a'
}

r = requests.get('https://tradeapi.samco.in/option/optionChain', params={
  'exchange':'NFO','searchSymbolName': 'TCS','strikePrice':'3800','optionType':'CE','expiryDate': '2024-04-25'
}, headers = headers)

print (r.json())

GET /option/optionChain

This API is used to search OptionChain for equity, derivatives and commodity scrips based on user provided search symbol and exchange name.

Parameters

Name	Type	Required	Description
exchange	string	false	Name of the exchange.Valid exchanges values (NFO/ BFO/ MCX/ CDS/ MFO).If the user does not provide an exchange name, by default considered as NFO.For trading with BFO, MFO, CDS and MCX, exchange is mandatory.
searchSymbolName	string	true	Trading Symbol of the scrip to be searched
expiryDate	string	false	From date in yyyy-MM-dd
strikePrice	string	true	The strike price is the predetermined price at which a put buyer can sell the underlying asset
optionType	string	false	Option Type (PE/CE).

Example responses

200 Response

{
    "serverTime": "10/04/24 12:22:26",
    "msgId": "2f030eb8-c689-4243-afb4-2e45e6fd0164",
    "status": "Success",
    "statusMessage": "OptionChain details retrived successfully. ",
    "optionChainDetails": [
        {
            "tradingSymbol": "TCS24APR3800CE",
            "exchange": "NSE",
            "symbol": "133428_NFO",
            "strikePrice": "3800.0000",
            "expiryDate": "2024-04-25",
            "instrument": "OPTSTK",
            "optionType": "CE",
            "underLyingSymbol": "TCS",
            "spotPrice": 3950.95,
            "lastTradedPrice": 190.95,
            "openInterest": 104300,
            "openInterestInLot": 596,
            "openInterestChange": 28350,
            "openInterestChangeInLot": 162,
            "oichangePer": "37.33",
            "volume": 55650,
            "bestBids": [
                {
                    "number": 1,
                    "quantity": "350",
                    "price": "190.90"
                },
                {
                    "number": 2,
                    "quantity": "525",
                    "price": "190.80"
                },
                {
                    "number": 3,
                    "quantity": "175",
                    "price": "190.50"
                },
                {
                    "number": 4,
                    "quantity": "350",
                    "price": "190.45"
                },
                {
                    "number": 5,
                    "quantity": "700",
                    "price": "190.35"
                }
            ],
            "bestAsks": [
                {
                    "number": 1,
                    "quantity": "175",
                    "price": "192.15"
                },
                {
                    "number": 2,
                    "quantity": "175",
                    "price": "192.20"
                },
                {
                    "number": 3,
                    "quantity": "175",
                    "price": "192.30"
                },
                {
                    "number": 4,
                    "quantity": "350",
                    "price": "192.40"
                },
                {
                    "number": 5,
                    "quantity": "350",
                    "price": "192.65"
                }
            ]
        }
    ]
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'
statusMessage	string	A message describing the result of the API call.
optionChainDetails	[object]	Scrips Details available for the provided search text.
tradingSymbol	string	Trading Symbol of the scrip.
exchange	string	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
symbol	string	Symbol Code of the trading Symbol
strikePrice	string	The strike price is the predetermined price at which a put buyer can sell the underlying asset.
expiryDate	string	Shows expiry date of a trading symbol.
instrument	string	Instrument Name.
optionType	string	Option Type (PE/CE).
underLyingSymbol	string	Root symbol of TradingSymbol
spotPrice	string	Spot price. Applicable in case of Futures and Options
lastTradedPrice	string	Price at which last transaction / trade is done
openInterest	string	Open interest is the Number of existing contracts held by buyers or sellers for any market for any given day.
openInterestChange	string	It shows Open interest change in Number of contracts held for market
oichangePer	string	It will shows the change % based on Open Interest
volume	string	Limit amount of a security traded on the specific day
bestBids	[object]	Most frequent trading bids for BUY
number	string	Sequence number for Bid/Ask
quantity	string	Quantity asked for trading.
price	string	Price asked for trading.
bestAsks	[object]	Most frequent trading asked for SELL
number	string	Sequence number for Bid/Ask
quantity	string	Quantity asked for trading.
price	string	Price asked for trading.

Future

Future Chain

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'e84ae32596c43f7d9260c9ece3d6b08e'
};

$.ajax({
  url: 'https://tradeapi.samco.in/future/futureChain?searchSymbolName=SENSEX&expiryDate=2024-04-12&exchange=BFO',
  method: 'get',
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
import json

headers = {
  'Accept': 'application/json',
  'x-session-token': 'e84ae32596c43f7d9260c9ece3d6b08e'
}

r = requests.get('https://tradeapi.samco.in/future/futureChain', params={
  'searchSymbolName': 'SENSEX','exchnage':'BFO','expiryDate':'2024-04-12'
}, headers = headers)

print (r.json())

GET /future/futureChain

This API is used to search futureChain for equity, derivatives, and commodity scripts based on the user-provided search symbol and exchange name.

Parameters

Name	Type	Required	Description
exchange	string	false	Name of the exchange.Valid exchanges values (NFO/BFO/CDS/MCX/MFO).If the user does not provide an exchange name, by default considered as NFO.For trading with CDS,BFO,MCX and MFO, exchange is mandatory.
searchSymbolName	string	true	Trading Symbol of the scrip to be searched
expiryDate	string	false	From date in yyyy-MM-dd

Example responses

200 Response

{
    "serverTime": "10/04/24 12:56:43",
    "msgId": "6f7ad177-15d9-44ee-a8c5-56b04e7f9afa",
    "status": "Success",
    "statusMessage": "Future chain details retrived successfully. ",
    "optionChainDetails": [
        {
            "tradingSymbol": "SENSEX24412FUT",
            "exchange": "BFO",
            "symbol": "859617_BFO",
            "expiryDate": "2024-04-12",
            "instrument": "IF",
            "underLyingSymbol": "SENSEX",
            "lastTradedPrice": "74871.0500",
            "openInterest": 1540,
            "openInterestInLot": 154,
            "openInterestChange": 1540,
            "openInterestChangeInLot": 154,
            "oichangePer": "Infinity",
            "volume": 2080,
            "bestBids": [
                {
                    "number": 1,
                    "quantity": "10",
                    "price": "74871.1016"
                },
                {
                    "number": 2,
                    "quantity": "10",
                    "price": "74855.8984"
                },
                {
                    "number": 3,
                    "quantity": "10",
                    "price": "74855.8516"
                },
                {
                    "number": 4,
                    "quantity": "10",
                    "price": "74855.2500"
                },
                {
                    "number": 5,
                    "quantity": "10",
                    "price": "74854.5000"
                }
            ],
            "bestAsks": [
                {
                    "number": 1,
                    "quantity": "10",
                    "price": "74877.7969"
                },
                {
                    "number": 2,
                    "quantity": "20",
                    "price": "74878.7031"
                },
                {
                    "number": 3,
                    "quantity": "10",
                    "price": "74878.7500"
                },
                {
                    "number": 4,
                    "quantity": "10",
                    "price": "74879.3984"
                },
                {
                    "number": 5,
                    "quantity": "10",
                    "price": "74879.6016"
                }
            ]
        }
    ]
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'
statusMessage	string	A message describing the result of the API call.
futureChainDetails	[object]	Scrips Details available for the provided search text.
tradingSymbol	string	Trading Symbol of the scrip.
exchange	string	Exchange information indicates which exchange each trading symbol comes from.
symbol	string	Symbol Code of the trading Symbol
expiryDate	string	Shows expiry date of a trading symbol.
instrument	string	Instrument Name.
underLyingSymbol	string	Root symbol of TradingSymbol
spotPrice	string	Spot price. Applicable in case of Futures and Options
lastTradedPrice	string	Price at which last transaction / trade is done
openInterest	string	Open interest is the Number of existing contracts held by buyers or sellers for any market for any given day.
openInterestChange	string	It shows Open interest change in Number of contracts held for market
oichangePer	string	It will shows the change % based on Open Interest
volume	string	Limit amount of a security traded on the specific day
bestBids	[object]	Most frequent trading bids for BUY
number	string	Sequence number for Bid/Ask
quantity	string	Quantity asked for trading.
price	string	Price asked for trading.
bestAsks	[object]	Most frequent trading asked for SELL
number	string	Sequence number for Bid/Ask
quantity	string	Quantity asked for trading.
price	string	Price asked for trading.

User Limits

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/limit/getLimits',
  method: 'get',
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.get('https://tradeapi.samco.in/limit/getLimits'
,headers = headers)
print r.json()

GET /limit/getLimits

Gets the user cash balances, available margin for trading in equity and commodity segments.

Example responses

200 Response

{
    "serverTime": "10/04/24 13:29:07",
    "msgId": "77bb4c9b-17fc-4465-8e30-02e80eaff78c",
    "status": "Success",
    "statusMessage": "User Limit details retrieved successfully",
    "equityLimit": {
        "grossAvailableMargin": "0.00",
        "payInToday": "0",
        "notionalCash": "0",
        "marginUsed": "0",
        "netAvailableMargin": "0.00"
    },
    "commodityLimit": {
        "grossAvailableMargin": "0.00",
        "payInToday": "0",
        "notionalCash": "0",
        "marginUsed": "0",
        "netAvailableMargin": "0.00"
    }
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	The status of the API response. It can be either 'Success' or 'Failure'
statusMessage	string	A message describing the result of the API call.
grossAvailableMargin	string	Total amount of margins or balances available for trading. Opening balance for current day
payInToday	string	Current day deposited amount
notionalCash	string	Additional Limit that may or may not be given by RMS for Trading.
collateralMarginAgainstShares	string	Margin against shares offered by SAMCO to their clients for trading in stock and shares.
marginUsed	string	The amount deducted from opening balance for trading on the current day, and the amount blocked for creating a position when user places an order.
netAvailableMargin	string	Actual margin available with user for Trading after making all necessary adjustments.
grossAvailableMargin	string	Total amount of margins or balances available for trading. Opening balance for current day
payInToday	string	Current day deposited amount
notionalCash	string	Additional Limit that may or may not be given by RMS for Trading.
collateralMarginAgainstShares	string	Margin against shares offered by SAMCO to their clients for trading in stock and shares.
marginUsed	string	The amount deducted from opening balance for trading on the current day, and the amount blocked for creating a position when user places an order.
netAvailableMargin	string	Actual margin available with user for Trading after making all necessary adjustments.

Orders

Place Order

Body parameter

requestBody={
  "symbolName":"BANKEX24APR49800PE",
  "exchange":"BFO",
  "transactionType":"BUY",
  "orderType":"SL-M",
  "quantity": "15",
  "disclosedQuantity":"",
  "orderValidity":"DAY",
  "productType":"NRML",
  "afterMarketOrderFlag":"",
  "marketProtection":"2",
  "triggerPrice":"1"
}

Code samples

var headers = {
  'Content-Type':'application/json',
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'
};

$.ajax({
  url: 'https://tradeapi.samco.in/order/placeOrder',
  method: 'post',
  data: JSON.stringify(requestBody),
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
import json

headers = {
  'Content-Type': 'application/json',
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.post('https://tradeapi.samco.in/order/placeOrder'
, data=json.dumps(requestBody)
, headers = headers)

print (r.json())

POST /order/placeOrder

This API allows you to place an equity/derivative order to the exchange i.e the place order request typically registers the order with OMS and when it happens successfully, a success response is returned. Successful placement of an order via the API does not imply its successful execution. To be precise, under normal scenarios, the whole flow of order execution starting with order placement, routing to OMS and transfer to the exchange, order execution, and confirmation from exchange happen real time. But due to various reasons like market hours, exchange related checks etc. This may not happen instantly. So when an order is successfully placed the placeOrder API returns an orderNumber in response, and in scenarios as above the actual order status can be checked separately using the orderStatus API call.This is for Placing CNC, MIS and NRML Orders

Parameters

Name	Type	Required	Description
symbolName	string	true	Pass "name" in "symbolName" parameter for Equity Cash symbols and "Trading Symbol" for all the F&O contracts ('name' and 'tradingSymbol' is available in ScripMaster.csv).
exchange	string	true	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ BFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, BFO, CDS and MCX, exchange is mandatory.
transactionType	string	true	Transaction type should be BUY or SELL
orderType	string	true	Type of order. It can be one of the following, MKT - Market Order,L- Limit Order,SL - Stop Loss Limit,SL-M - Stop loss market
quantity	string	true	Quantity with which order is being placed
disclosedQuantity	string	true	If provided should be minimum of 10% of actual quantity
price	string	false	Price mandatory when order type is L (Limit Order) OR SL(Stop Loss Limit)
priceType	string	true	Price type required to place an order. Valid price type - LTP/ATP , default is LTP. Applicable for BO orders only.
marketProtection	string	true	Percentage of MarketProtection required for ordertype MKT/SL-M to limit loss due to market price changes against the price with which order is placed. Default value is 3%.
orderValidity	string	true	Order validity can be DAY / IOC .Day is an order type which is valid for the whole trading day and stays pending till it is executed in respective trading day. IOC(Immediate Or Cancel) order type is where once the user punches the order, the order hits the exchange and if not executed immediately, the order stands cancelled
afterMarketOrderFlag	string	true	After Market Order Flag YES/NO
productType	string	true	Product Type of the order. It can be CNC (Cash and Carry)NRML (Normal),MIS (Intraday)
triggerPrice	string	false	The price at which an order should be triggered in case of SL, SL-M

Example responses

200 Response

{
    "serverTime": "15/04/24 11:57:43",
    "msgId": "aa1f9220-4a28-42ef-bc91-d363c1c6ac9f",
    "status": "Success",
    "orderNumber": "240415000064735",
    "statusMessage": "NRML Order request placed successfully",
    "exchangeOrderStatus": "REJECTED",
    "rejectionReason": "Required margin exceeds available margin.",
    "orderDetails": {
        "pendingQuantity": 0,
        "avgExecutionPrice": "0.00",
        "orderPlacedBy": "--",
        "tradingSymbol": "BANKEX24APR49800PE",
        "triggerPrice": "1.00",
        "exchange": "BFO",
        "totalQuantity": 15,
        "transactionType": "B",
        "productType": "NRML",
        "orderType": "SL",
        "quantity": 15,
        "filledQuantity": 0,
        "orderPrice": "0.65",
        "filledPrice": "0.00",
        "orderValidity": "DAY",
        "orderTime": "15/04/2024 11:57:43"
    }
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
orderNumber	string	Unique Order identifier generated after placing an order which could be used for tracking order status
status	string	Status of the order. It would be success or failure
statusMessage	string	Order placement status Message
exchangeOrderStatus	string	Status of the order execution at Exchange side, Most common values are PENDING, COMPLETE, REJECTED, CANCELLED, and OPEN
rejectionReason	string	If an order is rejected, cause of order rejection which comes as user friendly textual description
orderDetails	object	none
pendingQuantity	string	Quantity which is in waiting state to be filled in a specific trade
avgExecutionPrice	string	Average price at which the quantities were bought/sold during the day
orderPlacedBy	string	Client code of the user who placed the order
tradingSymbol	string	Trading Symbol of the scrip.
triggerPrice	string	The price at which an order should be triggered in case of SL, SL-M.
exchange	string	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
totalQuantity	string	Total Quantity
expiry	string	expiry date of trading symbol
transactionType	string	Type of the transaction, BUY / SELL.
productType	string	Product Type of order as placed by the user. It can be CNC (Cash and Carry),BO (Bracket Order),CO (Cover Order),NRML (Normal),MIS (Intraday).
orderType	string	Type of order user has placed . It can be one of the following, MKT - Market Order,L- Limit Order,SL - Stop Loss Limit,SL-M - Stop loss market.
quantity	string	Order Quantity as placed by the user
filledQuantity	string	Quantity which is filled in a specific trade. Can be less than or equal to the total quantity
orderPrice	string	Limit price entered at the time of placing the order.
filledPrice	string	Price at which exchange has filled the order
exchangeOrderNo	string	Order identifier at the exchange.
orderValidity	string	validity of the order
orderTime	string	Order placement time

Place BO Order

Body parameter

requestBody={
  "symbolName": "RELIANCE",
  "exchange": "NSE",
  "transactionType": "BUY",
  "orderType": "L",
  "quantity": "1",
  "disclosedQuantity": "1",
  "price": "1240.0",
  "priceType": "LTP",
  "orderValidity": "DAY",
  "productType": "BO",
  "squareOffValue": "5",
  "stopLossValue": "5",
  "valueType": "Ticks",
  "trailingStopLoss": "5"
}

Code samples

var headers = {
  'Content-Type':'application/json',
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'
};

$.ajax({
  url: 'https://tradeapi.samco.in/order/placeOrderBO',
  method: 'post',
  data: JSON.stringify(requestBody),
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
import json

headers = {
  'Content-Type': 'application/json',
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.post('https://tradeapi.samco.in/order/placeOrderBO'
, data=json.dumps(requestBody)
, headers = headers)

print (r.json())

POST /order/placeOrderBO

Parameters

Name	Type	Required	Description
body	object	false	none
symbolName	string	true	Pass "name" in "symbolName" parameter for Equity Cash symbols and "Trading Symbol" for all the F&O contracts ('name' and 'tradingSymbol' is available in ScripMaster.csv)
exchange	string	true	Name of the exchange.Valid exchanges values (NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with NFO, CDS and MCX, exchange is mandatory. BO orders not applicable to place in BSE exchange.
transactionType	string	true	Transaction type should be BUY or SELL
orderType	string	true	Type of order. It should be L- Limit Order
quantity	string	true	Quantity with which order is being placed
disclosedQuantity	string	true	If provided should be minimum of 10% of actual quantity
price	string	true	Price at which the order will be placed
priceType	string	true	Price type required to place an order. Valid price type - LTP/ATP , default is LTP. Applicable for BO orders only.
orderValidity	string	true	Order validity should be DAY .Day is an order type which is valid for the whole trading day and stays pending till it is executed in respective trading day.
productType	string	true	Product Type of the order. It can be BO (Bracket Order)
squareOffValue	string	true	Price difference from entry price at which the order should be squared off to limit losses (eg: if Order price is 300. Profit target is 305. So target = 5). Applicable for BO orders only
stopLossValue	string	true	Stoploss price difference from the entry price at which the order should be squared off (eg: if Order price is 300. Stoploss target is 295. So stop loss = 5). Applicable for both BO & CO
valueType	string	true	ValueType required to place an Order. Applicable for both Stop Loss Value and Square off value. Valid value types - Absolute/Ticks. Default is Absolute.Applicable for BO orders only.
trailingStopLoss	string	true	Incremental value set as % of change from the market price. Trailing stop moves as the price moves up. but, if the price starts to fall, the stop loss does not move (For example, if you buy a stock at Rs 100 and set a trailing stop loss value of Rs 2. If the stock price moves up to say Rs 105, the trailing stop loss value also would move up to be Rs 103 and stays Rs 2 less than the current market price. But if the stock price starts to fall and becomes Rs 103, trailing stop loss order will become a market order. Applicable for BO orders only

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "orderNumber": "190726000001077",
  "status": "Success",
  "exchangeOrderStatus": "Executed",
  "rejectionReason": "--",
  "statusMessage": "BO Order request placed successfully",
  "orderDetails": {
    "pendingQuantity": "0",
    "avgExecutionPrice": "1193.00",
    "orderPlacedBy": "DV9999",
    "tradingSymbol": "RELIANCE",
    "triggerPrice": "0.00",
    "exchange": "NSE",
    "totalQuantity": "1",
    "expiry": "--",
    "transactionType": "BUY",
    "productType": "BO",
    "orderType": "L",
    "quantity": "1",
    "filledQuantity": "1",
    "orderPrice": "1240.00",
    "filledPrice": "1240.0",
    "exchangeOrderNo": "1565067682526005486",
    "orderValidity": "DAY",
    "orderTime": "12/12/2019 16:20:09"
  }
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
orderNumber	string	Unique Order identifier generated after placing an order which could be used for tracking order status
status	string	Status of the order. It would be success or failure
exchangeOrderStatus	string	Status of the order execution at Exchange side, Most common values are PENDING, COMPLETE, REJECTED, CANCELLED, and OPEN
rejectionReason	string	If an order is rejected, cause of order rejection which comes as user friendly textual description
statusMessage	string	Order placement status Message
orderDetails	object	none
pendingQuantity	string	Quantity which is in waiting state to be filled in a specific trade
avgExecutionPrice	string	Average price at which the quantities were bought/sold during the day
orderPlacedBy	string	Client code of the user who placed the order
tradingSymbol	string	Trading Symbol of the scrip.
triggerPrice	string	The price at which an order should be triggered in case of SL, SL-M.
exchange	string	Name of the exchange.Valid exchanges values (NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with NFO, CDS and MCX, exchange is mandatory. BO orders not applicable for BSE exchange.
totalQuantity	string	Total Quantity
expiry	string	expiry date of trading symbol
transactionType	string	Type of the transaction, BUY / SELL.
productType	string	Product Type of order as placed by the user is BO (Bracket Order)
orderType	string	Type of order user has placed . It can be one of the following, MKT - Market Order,L- Limit Order,SL - Stop Loss Limit,SL-M - Stop loss market.
quantity	string	Order Quantity as placed by the user
filledQuantity	string	Quantity which is filled in a specific trade. Can be less than or equal to the total quantity
orderPrice	string	Limit price entered at the time of placing the order.
filledPrice	string	Price at which exchange has filled the order
exchangeOrderNo	string	Order identifier at the exchange.
orderValidity	string	validity of the order
orderTime	string	Order placement time

Place CO Order

Code samples

var headers = {
  'Content-Type':'application/json',
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/order/placeOrderCO',
  method: 'post',
  data: JSON.stringify(requestBody),
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Content-Type': 'application/json',
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.post('https://tradeapi.samco.in/order/placeOrderCO'
, data=json.dumps(requestBody)
, headers = headers)

print r.json()

POST /order/placeOrderCO

Body parameter

requestBody={
  "symbolName": "RELIANCE",
  "exchange": "BSE",
  "transactionType": "BUY",
  "orderType": "L",
  "quantity": "1",
  "disclosedQuantity": "1",
  "price": "1240.0",
  "orderValidity": "DAY",
  "productType": "CO",
  "triggerPrice": "1070.00"
}

Parameters

Name	Type	Required	Description
body	object	false	none
symbolName	string	true	Pass "name" in "symbolName" parameter for Equity Cash symbols and "Trading Symbol" for all the F&O contracts ('name' and 'tradingSymbol' is available in ScripMaster.csv)
exchange	string	true	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
transactionType	string	true	Transaction type should be BUY or SELL
orderType	string	true	Type of order. It can be one of the following, MKT - Market Order,L- Limit Order
quantity	string	true	Quantity with which order is being placed
disclosedQuantity	string	true	If provided should be minimum of 10% of actual quantity
price	string	true	Price at which the order will be placed
orderValidity	string	true	Order validity should be DAY .Day is an order type which is valid for the whole trading day and stays pending till it is executed in respective trading day.
productType	string	true	Product Type of the order. It can be CO (Cover Order))
triggerPrice	string	false	The price at which an order should be triggered

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "orderNumber": "190726000001077",
  "status": "Success",
  "exchangeOrderStatus": "Executed",
  "rejectionReason": "--",
  "statusMessage": "CO Order request placed successfully",
  "orderDetails": {
    "pendingQuantity": "0",
    "avgExecutionPrice": "1193.00",
    "orderPlacedBy": "DV9999",
    "tradingSymbol": "RELIANCE",
    "triggerPrice": "0.00",
    "exchange": "BSE",
    "totalQuantity": "1",
    "expiry": "--",
    "transactionType": "BUY",
    "productType": "CO",
    "orderType": "L",
    "quantity": "1",
    "filledQuantity": "1",
    "orderPrice": "1240.00",
    "filledPrice": "1240.0",
    "exchangeOrderNo": "1565067682526005486",
    "orderValidity": "DAY",
    "orderTime": "12/12/2019 16:20:09"
  }
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
orderNumber	string	Unique Order identifier generated after placing an order which could be used for tracking order status
status	string	Status of the order. It would be success or failure
exchangeOrderStatus	string	Status of the order execution at Exchange side, Most common values are PENDING, COMPLETE, REJECTED, CANCELLED, and OPEN
rejectionReason	string	If an order is rejected, cause of order rejection which comes as user friendly textual description
statusMessage	string	Order placement status Message
orderDetails	object	none
pendingQuantity	string	Quantity which is in waiting state to be filled in a specific trade
avgExecutionPrice	string	Average price at which the quantities were bought/sold during the day
orderPlacedBy	string	Client code of the user who placed the order
tradingSymbol	string	Trading Symbol of the scrip.
triggerPrice	string	The price at which an order should be triggered in case of SL, SL-M.
exchange	string	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
totalQuantity	string	Total Quantity
expiry	string	expiry date of trading symbol
transactionType	string	Type of the transaction, BUY / SELL.
productType	string	Product Type of order as placed by the user is CO (Cover Order)
orderType	string	Type of order user has placed . It can be one of the following, MKT - Market Order,L- Limit Order,SL - Stop Loss Limit,SL-M - Stop loss market.
quantity	string	Order Quantity as placed by the user
filledQuantity	string	Quantity which is filled in a specific trade. Can be less than or equal to the total quantity
orderPrice	string	Limit price entered at the time of placing the order.
filledPrice	string	Price at which exchange has filled the order
exchangeOrderNo	string	Order identifier at the exchange.
orderValidity	string	validity of the order
orderTime	string	Order placement time

Get Order Status

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/order/getOrderStatus?orderNumber=190707000000004',
  method: 'get',

  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.get('https://tradeapi.samco.in/order/getOrderStatus', params={
  'orderNumber': '190707000000004'
}, headers = headers)

print r.json()

GET /order/getOrderStatus

Get status of an order placed previously. This API returns all states of the orders,but not limited to open, pending, and partially filled ones.

Parameters

Name	Type	Required	Description
orderNumber	string	true	Order Number for which the user wants to check the order status

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "orderNumber": "190722000000243",
  "orderStatus": "Success",
  "statusMessage": "Requested MIS Order placed successfully",
  "orderDetails": {
    "pendingQuantity": "0",
    "avgExecutionPrice": "1193.00",
    "orderPlacedBy": "DV9999",
    "tradingSymbol": "RELIANCE",
    "triggerPrice": "0.00",
    "exchange": "BSE",
    "totalQuantity": "1",
    "expiry": "--",
    "transactionType": "BUY",
    "productType": "MIS",
    "orderType": "L",
    "quantity": "1",
    "filledQuantity": "1",
    "orderPrice": "1240.00",
    "filledPrice": "1240.0",
    "exchangeOrderNo": "1565067682526005486",
    "orderValidity": "DAY",
    "orderTime": "12/12/2019 16:20:09"
  }
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
orderNumber	string	Unique number generated at the exchange while placing an order
orderStatus	string	Status of the order at Exchange side, Most common values are PENDING, COMPLETE, REJECTED, CANCELLED, and OPEN
statusMessage	string	Status Message of the order
orderDetails	object	none
pendingQuantity	string	Quantity which is in waiting state to be filled in a specific trade
avgExecutionPrice	string	Average price at which the quantities were bought/sold during the day
orderPlacedBy	string	Client code of the user who placed the order
tradingSymbol	string	Trading Symbol of the scrip.
triggerPrice	string	The price at which an order should be triggered in case of SL, SL-M.
exchange	string	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
totalQuantity	string	Total Quantity
expiry	string	expiry date of trading symbol
transactionType	string	Type of the transaction, BUY / SELL.
productType	string	Product Type of order as placed by the user. It can be CNC (Cash and Carry),BO (Bracket Order),CO (Cover Order),NRML (Normal),MIS (Intraday).
orderType	string	Type of order user has placed . It can be one of the following, MKT - Market Order,L- Limit Order,SL - Stop Loss Limit,SL-M - Stop loss market.
quantity	string	Order Quantity as placed by the user
filledQuantity	string	Quantity which is filled in a specific trade. Can be less than or equal to the total quantity
orderPrice	string	Limit price entered at the time of placing the order.
filledPrice	string	Price at which exchange has filled the order
exchangeOrderNo	string	Order identifier at the exchange.
orderValidity	string	validity of the order
orderTime	string	Order placement time

Order Book

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/order/orderBook',
  method: 'get',

  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.get('https://tradeapi.samco.in/order/orderBook'
, headers = headers)
print r.json()

GET /order/orderBook

Orderbook retrieves and displays details of all orders placed by the user on a specific day. This API returns all states of the orders, namely, open, pending, rejected and executed ones.

Parameters

Name	Type	Required	Description

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "status": "Success",
  "statusMessage": "Request successful",
  "orderBookDetails": [
    {
      "orderNumber": "191206000000079",
      "exchange": "BSE",
      "tradingSymbol": "RELIANCE",
      "symbolDescription": "RELIANCE INDUSTRIES LTD.",
      "transactionType": "BUY",
      "productCode": "MIS",
      "orderType": "L",
      "orderPrice": "1560.15",
      "quantity": "13",
      "disclosedQuantity": "1",
      "triggerPrice": "1090.00",
      "marketProtection": "3",
      "orderValidity": "DAY",
      "orderStatus": "Complete",
      "orderValue": "20281.95",
      "instrumentName": "NA",
      "orderTime": "06-Dec-2019 13:47:04",
      "userId": "DV99999",
      "filledQuantity": "13",
      "fillPrice": "1560.15",
      "averagePrice": "1560.15",
      "unfilledQuantity": "0",
      "exchangeOrderId": "1575608622401000995",
      "rejectionReason": "NA",
      "exchangeConfirmationTime": "06-Dec-2019 14:14:47",
      "cancelledQuantity": "0",
      "referenceLimitPrice": "0.00",
      "coverOrderPercentage": "0.00",
      "orderRemarks": "--",
      "exchangeOrderNumber": "1575608622401000995",
      "symbol": "52310_NFO",
      "displayStrikePrice": "0.00",
      "displayNetQuantity": "10",
      "status": "complete",
      "exchangeStatus": "complete",
      "expiry": "--",
      "pendingQuantity": "0",
      "instrument": "--",
      "scripName": "--",
      "totalQuanity": "13",
      "optionType": "--",
      "orderPlaceBy": "DV99999",
      "lotQuantity": "1",
      "parentOrderId": "200824000050316"
    }
  ]
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	Response status. Can be Success or Failure
statusMessage	string	status Message
orderBookDetails	[object]	List of all orders with details during the day
orderNumber	string	Unique Order identifier generated after placing an order
exchange	string	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
tradingSymbol	string	Trading Symbol of the scrip.
symbolDescription	string	Scrip description
transactionType	string	Type of the transaction, BUY / SELL.
productCode	string	Product Type of order as placed by the user. It can be CNC (Cash and Carry),BO (Bracket Order),CO (Cover Order),NRML (Normal),MIS (Intraday).
orderType	string	Type of order user has placed . It can be one of the following, MKT - Market Order,L- Limit Order,SL - Stop Loss Limit,SL-M - Stop loss market.
orderPrice	string	Total price of a particular order
quantity	string	Total Quantity as placed by the user
disclosedQuantity	string	If provided should be minimun of 10% of actual quantity.
triggerPrice	string	The price at which an order should be triggered in case of SL, SL-M.
marketProtection	string	Percentage of MarketProtection required for ordertype MKT/SL-M to limit loss due to market price changes against the price with which order is placed. Default value is 3%.
orderValidity	string	Order validity can be DAY / IOC
orderStatus	string	Status of the order at Exchange side, either executed successfully or pending or rejected
orderValue	string	Value of the order
instrumentName	string	Name of the instrument
orderTime	string	Order placement time
userId	string	The client Code provided to you by SAMCO after opening an account.
filledQuantity	string	Quantity which is filled in a specific trade. Can be less than or equal to the total quantity
fillPrice	string	Price at which exchange has filled the order
averagePrice	string	Average trading price of the equity
unfilledQuantity	string	Quantity which is not filled in a partially filled order. Can be less than or equal to the total quantity
exchangeOrderId	string	Unique Order identifier generated from exchange
rejectionReason	string	If order is rejected, Cause of order Rejection
exchangeConfirmationTime	string	Order confirmation time at exchange
cancelledQuantity	string	cancelled quantity for partial cancelled orders
referenceLimitPrice	string	Limit Price reference
coverOrderPercentage	string	Percentage of cover order
orderRemarks	string	Remarks about order
exchangeOrderNumber	string	Unique Order identifier generated after placing an order
symbol	string	symbol about stock
displayStrikePrice	string	Shows the strick price
displayNetQuantity	string	Display the limit quantity of order
status	string	Status will display Executed/Pending/Rejected
exchangeStatus	string	ExchangeStatus will display Executed/Pending/Rejected
expiry	string	shows ExpiryDate of the stock
pendingQuantity	string	PendingQuantity will show pending quantity stock
instrument	string	Instrument is about the type of stock. FUT/OPT
scripName	string	Name of the scrip
totalQuanity	string	Total Quantity
optionType	string	Option Type (PE/CE).
orderPlaceBy	string	Client code of the user who placed the order
lotQuantity	string	lotQuantity represents the number of contracts contained in one derivative security.Applicable for F & O
parentOrderId	string	order Id of the parent order(it is applicable for only BO/CO orders)

TriggerOrders

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/order/getTriggerOrders?orderNumber=190707000000004',
  method: 'get',

  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.get('https://tradeapi.samco.in/order/getTriggerOrders', params={
  'orderNumber': '190707000000004'
}, headers = headers)

print r.json()

GET /order/getTriggerOrders

This API allows you to get the trigger order numbers in case of BO and CO orders so that their attribute values can be modified for BO orders, it will give the order identifiers. For Stop loss leg and target leg. Similarly for CO orders, it will return order identifier of stop loss leg only. Using the order identifier, the user would be able to modify the order attributes using the modifyOrder API. Refer modifyOrder API documentation for the parameters details.

Parameters

Name	Type	Required	Description
orderNumber	string	true	Order Number for which the user wants to check the order status

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "status": "Success",
  "statusMessage": "SubOrder details retrieved successfully.",
  "triggerOrders": [
    {
      "stopLossOrderNo": "191219000000063",
      "orderStatus": "Complete",
      "orderPrice": "351.20",
      "triggerPrice": "331.20"
    }
  ]
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	Response status. Can be Success or Failure
statusMessage	string	status Message
triggerOrders	[object]	Trigger order Details available for the provided OrderNumber.
stopLossOrderNo	string	Unique Order identifier generated from exchange
orderStatus	string	Status of the order at Exchange side, either executed successfully complete or trigger pending or cancelled
orderPrice	string	price of a particular order
triggerPrice	string	The price at which an order should be triggered

Modify Order

Code samples

var headers = {
  'Content-Type':'application/json',
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/order/modifyOrder/{orderNumber}',
  method: 'put',
  data: JSON.stringify(requestBody),
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Content-Type': 'application/json',
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.put('https://tradeapi.samco.in/order/modifyOrder/{orderNumber}'
, data=json.dumps(requestBody)
, headers = headers)

print r.json()

PUT /order/modifyOrder/{orderNumber}

User would be able to modify some attributes of an order as long as it is with open/pending status in system. For modification order identifier is mandatory. With order identifier you need to send the optional parameter(s) which needs to be modified. In case the optional parameters aren't sent, the default will be considered from the original order. Modifiable attributes include quantity, Order Type (L,MKT, SL,SL-M). This API cannot be used for modifying attributes of an executed/rejected/cancelled order. Only the attribute that needs to be modified should be sent in the request alongwith the Order Identifier.

Body parameter

requestBody={
  "orderType": "L",
  "quantity": "3",
  "disclosedQuantity": "1",
  "orderValidity": "DAY",
  "price": "1240.00",
  "triggerPrice": "1070.00",
  "parentOrderId": "190707000000004",
  "marketProtection": "5"
}

Parameters

Name	Type	Required	Description
orderNumber	string	true	Unique Order identifier of the order which needs to be modified
body	object	false	Type of order. MKT - Market Order,L - Limit Order, SL - Stop Loss Limit, SL-M - Stop Loss Market
orderType	string	false	Type of order user has placed . It can be one of the following, MKT - Market Order,L- Limit Order,SL - Stop Loss Limit,SL-M - Stop loss market.
quantity	string	false	Quantity of the order user wants to modify
disclosedQuantity	string	false	Quantity to disclose publicly
orderValidity	string	true	Order validity can be DAY or IOC
price	string	false	Price at which the order was placed
triggerPrice	string	false	The price at which an order should be triggered in case of SL, SL-M.
parentOrderId	string	true	ParentOrderId required to modify an order (applicable for BO orders only)
marketProtection	string	false	Percentage of MarketProtection required for ordertype MKT/SL-M to limit loss due to market price changes against the price with which order is placed. Default value is 3%.

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "orderNumber": "191206000000079",
  "status": "Success",
  "statusMessage": "MIS Order request placed successfully",
  "exchangeOrderStatus": "complete",
  "rejectionReason": "--",
  "orderDetails": {
    "pendingQuantity": "0",
    "avgExecutionPrice": "1193.00",
    "orderPlacedBy": "DV9999",
    "tradingSymbol": "RELIANCE",
    "triggerPrice": "0.00",
    "exchange": "BSE",
    "totalQuantity": "1",
    "expiry": "--",
    "transactionType": "BUY",
    "productType": "MIS",
    "orderType": "L",
    "quantity": "1",
    "filledQuantity": "1",
    "orderPrice": "1240.00",
    "filledPrice": "1240.0",
    "exchangeOrderNo": "1565067682526005486",
    "orderValidity": "DAY",
    "orderTime": "12/12/2019 16:20:09"
  }
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
orderNumber	string	Unique Order identifier generated after placing an order which could be used for tracking order status
status	string	Status of the order. It would be success or failure
statusMessage	string	Order placement status Message
exchangeOrderStatus	string	Status of the order execution at Exchange side, Most common values are PENDING, COMPLETE, REJECTED, CANCELLED, and OPEN
rejectionReason	string	If an order is rejected, cause of order rejection which comes as user friendly textual description
orderDetails	object	none
pendingQuantity	string	Quantity which is in waiting state to be filled in a specific trade
avgExecutionPrice	string	Average price at which the quantities were bought/sold during the day
orderPlacedBy	string	Client code of the user who placed the order
tradingSymbol	string	Trading Symbol of the scrip.
triggerPrice	string	The price at which an order should be triggered in case of SL, SL-M.
exchange	string	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
totalQuantity	string	Total Quantity
expiry	string	expiry date of trading symbol
transactionType	string	Type of the transaction, BUY / SELL.
productType	string	Product Type of order as placed by the user. It can be CNC (Cash and Carry),BO (Bracket Order),CO (Cover Order),NRML (Normal),MIS (Intraday).
orderType	string	Type of order user has placed . It can be one of the following, MKT - Market Order,L- Limit Order,SL - Stop Loss Limit,SL-M - Stop loss market.
quantity	string	Order Quantity as placed by the user
filledQuantity	string	Quantity which is filled in a specific trade. Can be less than or equal to the total quantity
orderPrice	string	Limit price entered at the time of placing the order.
filledPrice	string	Price at which exchange has filled the order
exchangeOrderNo	string	Order identifier at the exchange.
orderValidity	string	validity of the order
orderTime	string	Order placement time

Cancel BO Order

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/order/exitBO?orderNumber=190707000000004',
  method: 'delete',

  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.delete('https://tradeapi.samco.in/order/exitBO', params={
  'orderNumber': '190707000000004'
}, headers = headers)

print r.json()

DELETE /order/exitBO

For Cancellation/exit of BO orders pass main leg Order number. If main leg is in Open/Pending state that order will be cancelled. If the main leg is executed and the sublegs are created and in open/Trigger pending state, the order will be exited. If the main leg is executed and if either of Stop loss or target is hit, API will return error message "SubOrder is in Executed status. Cannot exit/cancel such orders."

Parameters

Name	Type	Required	Description
orderNumber	string	true	The main order identifier provided as an input which needs to be exited.

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "status": "Success",
  "orderNumber": "190722000000243",
  "statusMessage": "Order cancellation request placed successfully"
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	Status of the order cancellation request. Can be success or failure
orderNumber	string	Unique Order identifier generated after placing an order
statusMessage	string	Status Message for the order cancellation request

Cancel CO Order

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/order/exitCO?orderNumber=190707000000004',
  method: 'delete',

  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.delete('https://tradeapi.samco.in/order/exitCO', params={
  'orderNumber': '190707000000004'
}, headers = headers)

print r.json()

DELETE /order/exitCO

For Cancellation/exit of CO orders pass main leg Order number. If main leg is in Open/Pending state that order will be cancelled. If the main leg is executed and the sublegs are created and in open/Trigger pending state, the order will be exited. If the main leg is executed and if Stop loss is hit, API will return error message "SubOrder is in Executed status. Cannot exit/cancel such orders."

Parameters

Name	Type	Required	Description
orderNumber	string	true	The main order identifier provided as an input which needs to be exited.

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "status": "Success",
  "orderNumber": "190722000000243",
  "statusMessage": "Order cancellation request placed successfully"
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	Status of the order cancellation request. Can be success or failure
orderNumber	string	Unique Order identifier generated after placing an order
statusMessage	string	Status Message for the order cancellation request

Cancel Order

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/order/cancelOrder?orderNumber=190707000000004',
  method: 'delete',

  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.delete('https://tradeapi.samco.in/order/cancelOrder', params={
  'orderNumber': '190707000000004'
}, headers = headers)

print r.json()

DELETE /order/cancelOrder

An order which is open or pending in system can be cancelled. In other words, cancellation cannot be initiated for already Executed, Rejected orders.This is for CNC, MIS and NRML Orders.

Parameters

Name	Type	Required	Description
orderNumber	string	true	The order identifier provided as an input which needs to be cancelled

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "status": "Success",
  "orderNumber": "190722000000243",
  "statusMessage": "Order cancellation request placed successfully"
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	Status of the order cancellation request. Can be success or failure
orderNumber	string	Unique Order identifier generated after placing an order
statusMessage	string	Status Message for the order cancellation request

TradeBook

Trade Book

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/trade/tradeBook',
  method: 'get',

  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.get('https://tradeapi.samco.in/trade/tradeBook'
, headers = headers)

print r.json()

GET /trade/tradeBook

Details of all successfully executed orders placed by the user.

Parameters

Name	Type	Required	Description

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "status": "Success",
  "statusMessage": "Request successful",
  "tradeBookDetails": [
    {
      "orderNumber": "191206000000079",
      "exchange": "BSE",
      "tradingSymbol": "RELIANCE",
      "symbolDescription": "RELIANCE INDUSTRIES LTD.",
      "transactionType": "BUY",
      "productCode": "MIS",
      "orderType": "L",
      "orderPrice": "1560.15",
      "quantity": "13",
      "disclosedQuantity": "1",
      "triggerPrice": "0.00",
      "marketProtection": "3",
      "orderValidity": "DAY",
      "orderStatus": "Complete",
      "orderValue": "20281.95",
      "instrumentName": "NA",
      "orderTime": "06-Dec-2019 13:47:04",
      "userId": "DV99999",
      "filledQuantity": "13",
      "unfilledQuantity": "0",
      "exchangeConfirmationTime": "05:06:12",
      "coverOrderPercentage": "%",
      "exchangeOrderNumber": "1571202357797000054",
      "tradeNumber": "195300",
      "tradePrice": "1560.15",
      "tradeDate": "06DEC2019",
      "tradeTime": "02:14:47 PM",
      "strikePrice": "800.00",
      "optionType": "XX",
      "lastTradePrice": "2,077.00",
      "expiry": "NA"
    }
  ]
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	Response status. Can be Success or Failure
statusMessage	string	status Message
tradeBookDetails	[object]	Get list of TradeBookEntries.
orderNumber	string	Unique Order identifier generated after placing an order
exchange	string	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
tradingSymbol	string	Trading Symbol of the scrip.
symbolDescription	string	Scrip description
transactionType	string	Type of the transaction, BUY / SELL.
productCode	string	Product Type of order as placed by the user. It can be CNC (Cash and Carry),BO (Bracket Order),CO (Cover Order),NRML (Normal),MIS (Intraday).
orderType	string	Type of order user has placed . It can be one of the following, MKT - Market Order,L- Limit Order,SL - Stop Loss Limit,SL-M - Stop loss market.
orderPrice	string	Limit price of a particular order
quantity	string	It is the order quantity
disclosedQuantity	string	Quantity to disclose to public in the market
triggerPrice	string	The price at which an order should be triggered in case of SL, SL-M.
marketProtection	string	Percentage of MarketProtection required for ordertype MKT/SL-M to limit loss due to market price changes against the price with which order is placed. Default value is 3%.
orderValidity	string	Order validity can be DAY / IOC
orderStatus	string	Status of the order at Exchange side, either executed successfully or pending or rejected
orderValue	string	Value of the order
instrumentName	string	Name of the instrument
orderTime	string	Order placement time
userId	string	The client Code provided to you by SAMCO after opening an account.
filledQuantity	string	Quantity which is filled in a specific trade. Can be less than or equal to the total quantity
unfilledQuantity	string	Quantity which is not filled in a partially filled order. Can be less than or equal to the total quantity
exchangeConfirmationTime	string	Order confirmation time at exchange
coverOrderPercentage	string	Percentage of cover order
exchangeOrderNumber	string	Unique Order identifier generated after placing an order.
tradeNumber	string	Unique trade identifier generated for every trade.
tradePrice	string	Price of a trade.
tradeDate	string	Date of a trade.
tradeTime	string	Time of a trade.
strikePrice	string	The strike price is the predetermined price at which a put buyer can sell the underlying asset.
optionType	string	Option Type (PE/CE).
lastTradePrice	string	Price at which last transaction/trade is done
expiry	string	Shows expiry date of a trading symbol.

Positions

User Positions

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/position/getPositions?positionType=DAY',
  method: 'get',

  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.get('https://tradeapi.samco.in/position/getPositions', params={
  'positionType': 'DAY'
}, headers = headers)

print r.json()

GET /position/getPositions

Get position details of the user (The details of equity, derivative, commodity, currency borrowed or owned by the user).

Parameters

Name	Type	Required	Description
positionType	string	true	Position type can be DAY/NET. If Position type is “DAY”, fetch current day position details, If Position Type is “NET”, fetch carry forward position details

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "status": "Success",
  "statusMessage": "Request successful",
  "positionSummary": {
    "gainingTodayCount": "2",
    "losingTodayCount": "2",
    "totalGainAndLossAmount": "0.00",
    "dayGainAndLossAmount": "-4910.00"
  },
  "positionDetails": [
    {
      "averagePrice": "1560.15",
      "exchange": "BSE",
      "markToMarketPrice": "-182.70",
      "lastTradedPrice": "1,550.00",
      "previousClose": "1552.55",
      "productCode": "CNC",
      "symbolDescription": "RELIANCE INDUSTRIES LTD.",
      "tradingSymbol": "RELIANCE",
      "calculatedNetQuantity": "18.0",
      "averageBuyPrice": "1560.15",
      "averageSellPrice": "0.00",
      "boardLotQuantity": "1",
      "boughtPrice": "28082.70",
      "buyQuantity": "18",
      "carryForwardQuantity": "0",
      "carryForwardValue": "0.00",
      "multiplier": "1",
      "netPositionValue": "-182.70",
      "netQuantity": "18",
      "netValue": "-182.70",
      "positionType": "DAY",
      "positionConversions": "CNC, NRML",
      "soldValue": "0.00",
      "transactionType": "BUY",
      "realizedGainAndLoss": "0.00",
      "unrealizedGainAndLoss": "-182.70",
      "companyName": "RELIANCE INDUSTRIES LTD.",
      "expiryDate": "--",
      "optionType": "--"
    }
  ]
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	Response status. Can be Success or Failure
statusMessage	string	status Message
positionSummary	object	none
gainingTodayCount	string	Count of scrips which are gaining in value in a trading day
losingTodayCount	string	Count of scrips which are losing in value in a trading day
totalGainAndLossAmount	string	Total amount of Gain / Loss for all existing positions since their creation
dayGainAndLossAmount	string	Amount of Gain / Loss for all positions on a specific trading day
positionDetails	[object]	Details of Day/Net positions as queried
averagePrice	string	Average trading price of the equity
exchange	string	Name of the exchange.Valid exchanges values (BSE/ NSE) If the user does not provide an exchange name, by default considered as NSE.
markToMarketPrice	string	Price change between previous close price and current price
lastTradedPrice	string	Price at which last transaction/trade is done
previousClose	string	Previous close refers to the prior day's final price of security when the market officially closes for the day.
productCode	string	Type of the product, allowable type is CNC
symbolDescription	string	Scrip Description
tradingSymbol	string	Symbol name of the scrip.
calculatedNetQuantity	string	Quantity left after the day
averageBuyPrice	string	Average price at which the quantities were bought
averageSellPrice	string	Average price at which the quantities were sold
boardLotQuantity	string	The standardized number of shares decided by the exchange as a trading unit
boughtPrice	string	Price at which quantities were bought during the day
buyQuantity	string	Total quantity brought and added to the position during the day
carryForwardQuantity	string	Quantity bought or sold in previous session
carryForwardValue	string	Net value of the position in previous session
multiplier	string	The lot size multiplier used to calculate Profit and Loss
netPositionValue	string	Net value of the position during the day
netQuantity	string	Limit quantity of the position
netValue	string	Net value of the bought quantities
positionType	string	Type of the position, Ex -Day/Net
positionConversions	[string]	Different Product types the user can Convert an existing position to
soldValue	string	Total value of sold quantities
transactionType	string	Type of the transaction, BUY / SELL.
realizedGainAndLoss	string	The Profit and Loss returns from a closed position
unrealizedGainAndLoss	string	The Profit and Loss returns from a open position
companyName	string	Full name of the trading company
expiryDate	string	Expiry date of the scrip
optionType	string	Option Type (PE/CE).

Position Conversion

Code samples

var headers = {
  'Content-Type':'application/json',
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/position/convertPosition',
  method: 'post',
  data: JSON.stringify(requestBody),
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Content-Type': 'application/json',
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.post('https://tradeapi.samco.in/position/convertPosition'
, data=json.dumps(requestBody)
, headers = headers)

print r.json()

POST /position/convertPosition

Convert an existing position of a margin product to a different margin product type. All or a subset of an existing position quantity can be converted to a different product type.The available margin product types are MARGIN_INTRADAY_SQUAREOFF(MIS), CASHNCARRY(CNC), NORMAL(NRML).

Body parameter

requestBody={
  "symbolName": "RELIANCE",
  "exchange": "BSE",
  "transactionType": "BUY",
  "positionType": "DAY",
  "netQuantity": "18",
  "quantityToConvert": "2",
  "fromProductType": "MIS",
  "toProductType": "CNC"
}

Parameters

Name	Type	Required	Description
body	object	false	none
symbolName	string	true	Symbol name of the scrip
exchange	string	true	Name of the exchange. If the user does not provide an exchange name, by default considered as NSE
transactionType	string	true	Transaction type can be either BUY or SELL
positionType	string	true	DAY or NET
netQuantity	string	true	Total quantity of the position
quantityToConvert	string	true	Quantity to be converted. Can be less than or equal to netQuantity
fromProductType	string	true	The existing product type of the position . It can be CNC (Cash and Carry),NRML (Normal),MIS (Intraday)
toProductType	string	true	The target product type user wants to convert to . It can be CNC (Cash and Carry),NRML (Normal),MIS (Intraday)

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "status": "Success",
  "statusMsg": "Position Conversion from MIS to CNC successful"
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	Status of the position conversion request.Success / Failure
statusMsg	string	Status message of position conversion request

Position Square Off

Code samples

var headers = {
  'Content-Type':'application/json',
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/position/squareOff',
  method: 'post',
  data: JSON.stringify(requestBody),
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Content-Type': 'application/json',
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.post('https://tradeapi.samco.in/position/squareOff'
, data=json.dumps(requestBody)
, headers = headers)

print r.json()

POST /position/squareOff

SqareOff existing position. Mostly used in day trading, in which user buy or sell a particular quantity of a stock and later in the day reverse the transaction to earn a profit.

Body parameter

requestBody={

  "positionSquareOffRequestList": [
    {
      "exchange": "NSE",
      "symbolName": "TCS",
      "productType": "MIS",
      "netQuantity": "250",
      "transactionType": "BUY"
    },
    {
      "exchange": "BSE",
      "symbolName": "INFY",
      "productType": "MIS",
      "netQuantity": "25",
      "transactionType": "SELL"
    }
  ]
}

Parameters

Name	Type	Required	Description
body	object	false	none
positionSquareOffRequestList	[object]	false	List of the position squareOff user wants to do
exchange	string	false	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
symbolName	string	false	Symbol name of the scrip.
productType	string	false	Product type of the existing position.It can be CNC (Cash And Carry),NRML (Normal),MIS (Intraday)
netQuantity	string	false	Total quantity held in existing position
transactionType	string	false	Type of the transaction, BUY / SELL.
positionSquareOffList	[object]	false	none
userId	string	true	The client Code provided to you by SAMCO after opening an account.
exchange	string	false	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
symbolName	string	false	Symbol name of the scrip.
productType	string	false	Product type of the existing position.It can be CNC (Cash And Carry),NRML (Normal),MIS (Intraday)
netQuantity	string	false	Total quantity held in existing position
transactionType	string	false	Type of the transaction, BUY / SELL.

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "positionSquareOffResponseList": [
    {
      "serverTime": "12/12/19 16:20:11",
      "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
      "status": "Success",
      "statusMessage": "Request successful"
    }
  ]
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
positionSquareOffResponseList	[object]	List of the PositionSquareOff end of the day
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	Response status. Can be Success or Failure
statusMessage	string	status Message

Holdings

User Holdings

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/holding/getHoldings',
  method: 'get',

  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.get('https://tradeapi.samco.in/holding/getHoldings'
, headers = headers)
print r.json()

GET /holding/getHoldings

Get the details of the Stocks which client is holding. Here, you will be able to get the Client holdings which are bought under ‘CNC’ product type and are not sold yet.

Parameters

Name	Type	Required	Description

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "status": "Success",
  "statusMessage": "Request successful",
  "holdingSummary": {
    "gainingTodayCount": "2",
    "losingTodayCount": "2",
    "totalGainAndLossAmount": "0.00",
    "dayGainAndLossAmount": "-4910.00",
    "portfolioValue": "343.80"
  },
  "holdingDetails": [
    {
      "averagePrice": "1560.15",
      "exchange": "BSE",
      "markToMarketPrice": "-182.70",
      "lastTradedPrice": "1,550.00",
      "previousClose": "1552.55",
      "productCode": "CNC",
      "symbolDescription": "RELIANCE INDUSTRIES LTD.",
      "tradingSymbol": "RELIANCE",
      "totalGainAndLoss": "0.00",
      "calculatedNetQuantity": "18.0",
      "holdingsQuantity": "3",
      "collateralQuantity": "2",
      "holdingsValue": "436.46",
      "isin": "INE917I01010",
      "sellableQuantity": "1",
      "totalMarketToMarketPrice": "0"
    }
  ]
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	Response status. Can be Success or Failure
statusMessage	string	status Message
holdingSummary	object	none
gainingTodayCount	string	Count of scrips which are gaining in value in a trading day
losingTodayCount	string	Count of scrips which are losing in value in a trading day
totalGainAndLossAmount	string	Total amount of Gain / Loss for all existing positions since their creation
dayGainAndLossAmount	string	Amount of Gain / Loss for all positions on a specific trading day
portfolioValue	string	Value of the portfolio.
holdingDetails	[object]	Details of the user holdings.
averagePrice	string	Average trading price of the equity
exchange	string	Name of the exchange.Valid exchanges values (BSE/ NSE) If the user does not provide an exchange name, by default considered as NSE.
markToMarketPrice	string	Price change between previous close price and current price
lastTradedPrice	string	Price at which last transaction/trade is done
previousClose	string	Previous close refers to the prior day's final price of security when the market officially closes for the day.
productCode	string	Type of the product, allowable type is CNC
symbolDescription	string	Scrip Description
tradingSymbol	string	Trading Symbol of the scrip.
totalGainAndLoss	string	Total Gain/Loss for all existing positions since their creation
calculatedNetQuantity	string	Quantity left after the day
holdingsQuantity	string	Currently holding(CNC) quantity
collateralQuantity	string	Quantity of loan against shares offered by SAMCO to their clients for trading in stock and shares.
holdingsValue	string	Limit value of the available holdings.
isin	string	The standard ISIN representing stocks uniquely at international level. It is same for every exchange.
sellableQuantity	string	Quantity which is open for sale.
totalMarketToMarketPrice	string	Total price change between previous close price and current price

IntraDay candle data

Intraday candle data

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/intraday/candleData?symbolName=INFY&fromDate=2019-11-11%2010%3A00%3A00',
  method: 'get',

  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.get('https://tradeapi.samco.in/intraday/candleData', params={
  'symbolName': 'INFY',  'fromDate': '2019-11-11 10:00:00'
}, headers = headers)

print r.json()

GET /intraday/candleData

Gets the Intraday candle data such as Open, high, low, close and volume within specific time period per min for a specific symbol.

Parameters

Name	Type	Required	Description
exchange	string	false	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
symbolName	string	true	Symbol name of the scrip.
fromDate	string	true	From date in yyyy-MM-dd hh:mm:ss
toDate	string	false	To date in yyyy-MM-dd hh:mm:ss
interval	string	false	Interval of data, By default interval is considered as 1 min

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "status": "Success",
  "statusMessage": "Request successful",
  "intradayCandleData": [
    {
      "dateTime": "2019-11-11 10:01:00",
      "open": "689.9",
      "high": "694.0",
      "low": "682.75",
      "close": "688.0",
      "volume": "600344"
    }
  ]
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	Response status. Can be Success or Failure
statusMessage	string	status Message
intradayCandleData	[object]	Get List of IntraDayCandleData .
dateTime	string	Date for which CandleData shown
open	string	Opening price of a market snapshot
high	string	High value of market snapshot
low	string	Low value of market snapshot
close	string	Close value of market snapshot
volume	string	Limit amount of a security traded on the specific day

Index IntraDay candle data

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/intraday/indexCandleData?indexName=SENSEX&fromDate=2020-03-11%2010%3A00%3A00',
  method: 'get',

  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.get('https://tradeapi.samco.in/intraday/indexCandleData', params={
  'indexName': 'SENSEX',  'fromDate': '2020-03-11 10:00:00'
}, headers = headers)

print r.json()

GET /intraday/indexCandleData

Gets the Index intraday candle data such as Open, high, low, close and volume within specific time period per min for a specific index.

Supports Following List of Index names:

BSE CG	SENSEX	BSE CD	NIFTY50 PR 1x INV
BSE IT	METAL	OILGAS	NIFTY50 PR 2x LEV
BSEIPO	GREENX	POWER	NIFTY50 TR 1x INV
CARBON	BASMTR	CDGS	NIFTY50 TR 2x LEV
BSEFMC	BSE HC	ALLCAP	NIFTY50 TR 2x LEV
REALTY	SMEIPO	DOL30	NIFTY Mid LIQ 15
LRGCAP	MIDSEL	SMLSEL	NIFTY100 LIQ 15
SNXT50	SNSX50	NIFTY 50	NIFTY Quality 30
NIFTY BANK	NIFTY NEXT 50	DOL100	NIFTY MIDCAP 50
NIFTY 100	NIFTY 200	NIFTY 500	NIFTY FIN SERVICE
NIFTY AUTO	NIFTY FMCG	NIFTY IT	NIFTY COMMODITIES
NIFTY MEDIA	NIFTY METAL	NIFTY PHARMA	NIFTY CONSUMPTION
NIFTY PSU BANK	NIFTY PVT BANK	NIFTY REALTY	NIFTY GROWSECT 15
NIFTY CPSE	NIFTY ENERGY	NIFTY INFRA	NIFTY DIV OPPS 50
NIFTY MNC	NIFTY PSE	NIFTY SERV SECTOR	NIFTY MID100 FREE
DOL200	TECK	BSEPSU	NIFTY SML100 FREE
AUTO	BANKEX	INDIA VIX	NIFTY50 VALUE 20

Parameters

Name	Type	Required	Description
indexName	string	true	Index name of the scrip
fromDate	string	true	From date in yyyy-MM-dd hh:mm:ss
toDate	string	false	To date in yyyy-MM-dd hh:mm:ss
interval	string	false	Interval of data, By default interval is considered as 1 min

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "status": "Success",
  "statusMessage": "Index details retrieved successfully.",
  "indexIntraDayCandleData": [
    {
      "dateTime": "2019-11-11 10:01:00",
      "open": "689.9",
      "high": "694.0",
      "low": "682.75",
      "close": "688.0",
      "volume": "600344"
    }
  ]
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	It would be success or failure
statusMessage	string	Status message of the Index request
indexIntraDayCandleData	[object]	Get List of IndexIntraDayCandleData .
dateTime	string	Date for which CandleData shown
open	string	Opening price of a market snapshot
high	string	High value of market snapshot
low	string	Low value of market snapshot
close	string	Close value of market snapshot
volume	string	Limit amount of a security traded on the specific day

Historical candle data

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/history/candleData?symbolName=INFY&fromDate=2019-10-11',
  method: 'get',

  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.get('https://tradeapi.samco.in/history/candleData', params={
  'symbolName': 'INFY',  'fromDate': '2019-10-11'
}, headers = headers)

print r.json()

GET /history/candleData

Gets the historical candle data such as Open, high, low, close, last traded price and volume within specific dates for a specific symbol. From date is mandatory. End date is optional and defaults to yesterday.

Parameters

Name	Type	Required	Description
exchange	string	false	Name of the exchange.Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
symbolName	string	true	Symbol name of the scrip.
fromDate	string	true	From date in yyyy-MM-dd
toDate	string	false	To date in yyyy-MM-dd

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "status": "Success",
  "statusMessage": "Request successful",
  "historicalCandleData": [
    {
      "date": "2019-11-01",
      "open": "689.9",
      "high": "694.0",
      "low": "682.75",
      "close": "688.0",
      "ltp": "688.0",
      "volume": "600344"
    }
  ]
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	Response status. Can be Success or Failure
statusMessage	string	status Message
historicalCandleData	[object]	Get List of CandleData .
date	string	Date for which CandleData shown
open	string	Opening price of a market snapshot
high	string	High value of market snapshot
low	string	Low value of market snapshot
close	string	Close value of market snapshot
ltp	string	Price at which last transaction / trade is done
volume	string	Limit amount of a security traded on the specific day

Index Historical CandleData

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'c5c81c20f0fe81ceb45f93d3621d0938'

};

$.ajax({
  url: 'https://tradeapi.samco.in/history/indexCandleData?indexName=SENSEX&fromDate=2020-03-09',
  method: 'get',

  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token': 'c5c81c20f0fe81ceb45f93d3621d0938'
}

r = requests.get('https://tradeapi.samco.in/history/indexCandleData', params={
  'indexName': 'SENSEX',  'fromDate': '2020-03-09'
}, headers = headers)

print r.json()

GET /history/indexCandleData

Gets the Index historical candle data such as Open, high, low, close, last traded price and volume within specific dates for a specific index. From date is mandatory. End date is optional and defaults to Today.

Supports Following List of Index names:

BSE CG	SENSEX	BSE CD	NIFTY50 PR 1x INV
BSE IT	METAL	OILGAS	NIFTY50 PR 2x LEV
BSEIPO	GREENX	POWER	NIFTY50 TR 1x INV
CARBON	BASMTR	CDGS	NIFTY50 TR 2x LEV
BSEFMC	BSE HC	ALLCAP	NIFTY50 TR 2x LEV
REALTY	SMEIPO	DOL30	NIFTY Mid LIQ 15
LRGCAP	MIDSEL	SMLSEL	NIFTY100 LIQ 15
SNXT50	SNSX50	NIFTY 50	NIFTY Quality 30
NIFTY BANK	NIFTY NEXT 50	DOL100	NIFTY MIDCAP 50
NIFTY 100	NIFTY 200	NIFTY 500	NIFTY FIN SERVICE
NIFTY AUTO	NIFTY FMCG	NIFTY IT	NIFTY COMMODITIES
NIFTY MEDIA	NIFTY METAL	NIFTY PHARMA	NIFTY CONSUMPTION
NIFTY PSU BANK	NIFTY PVT BANK	NIFTY REALTY	NIFTY GROWSECT 15
NIFTY CPSE	NIFTY ENERGY	NIFTY INFRA	NIFTY DIV OPPS 50
NIFTY MNC	NIFTY PSE	NIFTY SERV SECTOR	NIFTY MID100 FREE
DOL200	TECK	BSEPSU	NIFTY SML100 FREE
AUTO	BANKEX	INDIA VIX	NIFTY50 VALUE 20

Parameters

Name	Type	Required	Description
indexName	string	true	Index name of the scrip
fromDate	string	true	From date in yyyy-MM-dd
toDate	string	false	To date in yyyy-MM-dd

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "status": "Success",
  "statusMessage": "Index details retrieved successfully.",
  "indexCandleData": [
    {
      "date": "2019-11-01",
      "open": "689.9",
      "high": "694.0",
      "low": "682.75",
      "close": "688.0",
      "ltp": "688.0",
      "volume": "600344"
    }
  ]
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	It would be success or failure
statusMessage	string	Status message of the Index request
indexCandleData	[object]	Get List of IndexData .
date	string	Date for which CandleData shown
open	string	Opening price of a market snapshot
high	string	High value of market snapshot
low	string	Low value of market snapshot
close	string	Close value of market snapshot
ltp	string	Price at which last transaction / trade is done
volume	string	Limit amount of a security traded on the specific day

Streaming Data

Streaming Market Data

Code samples

import json
import websocket
import threading
import pandas as pd
from typing import Any
from snapi_py_client.snapi_bridge import StocknoteAPIPythonBridge
samco = StocknoteAPIPythonBridge()
samco.set_session_token(sessionToken="17f72da7e320807ba324f20566135fda")
symbol_list=["3880_NSE","10753_NSE","14847_NSE","2866_NSE","30125_NSE","2495_NSE","9223_NSE","11471_NSE"]
df_symbols = pd.DataFrame({"symbol": symbol_list})
# Convert the DataFrame to a JSON string
json_data = df_symbols.to_json(orient="records")
count = 0
start_time = None
quit_flag = False
def on_message(ws, msg):
    global count, start_time,quit_flag
    print("Actual Market Data  Value::"+msg)
def on_error(ws, error):
    print (error)
def on_close(ws):
    print ("Connection Closed")
def on_open(ws):
    print ("Sending json")
    data = (
        '{"request":{"streaming_type":"quote2", "data":{"symbols":'
        + json_data
        + '},"request_type":"subscribe", "response_format":"json"}}'
    )
    ws.send(data)
    ws.send("\n")
headers = {'x-session-token':session}
websocket.enableTrace(True)
def connect_websocket():
    ws = websocket.WebSocketApp("wss://stream.stocknote.com",on_open = on_open, on_message = on_message, on_error = on_error, on_close = on_close, header = headers)
    wst = threading.Thread(target=ws.run_forever())
if __name__ == "__main__":
    try:
        connect_websocket()
    except Exception as err:
        print(err)
        print("connect failed")

wss:/stream.stocknote.com/.

Samco Trade API platform provides the Broadcast API, as the most effective way to receive market data for instruments across all exchanges during live market hours. The API provides continuous streaming data of market data based on user request, and primarily consists of fields such as 5 levels of bid/offer market depth data etc.

The API uses WebSocket protocol to establish a dedicated TCP connection after an HTTP handshake to receive streaming quotes and thereby provides seamless streaming of market data. You need to use a WebSocket client to connect to our broadcast API. If you have already subscribed to our Trade API services, you will be able to access broadcast API too.

Body parameter

requestBody={
  "streaming_type": "quote2",
  "symbols": "[{'symbol':'-23'},{'symbol':'30125_NSE'},{'symbol':'3880_NSE'}]",
  "request_type": "subscribe",
  "response_format": "JSON"
}

Parameters

Name	Type	Required	Description
body	object	false	none
streaming_type	string	true	Streaming type.Added for future use.Pass this value as “marketdata” always
symbols	[string]	true	List of symbols contains listing nos used to get marketdata.
request_type	string	true	Request type.This can be Subscribe/Unsubscribe. Subscribe - Receive continuous quote data. UnSubscribe - Stop receiving the continuous quote data. *It's important to unsubscribe when the streaming is no longer needed.
response_format	string	true	Response data format. Currently supports json only

Example responses

200 Response

{
  "response": {
    "data": {
      "askValues": [
        {
          "no": "5",
          "price": "89.20",
          "qty": "4034"
        },
        {
          "no": "21",
          "price": "89.25",
          "qty": "11106"
        },
        {
          "no": "24",
          "price": "89.30",
          "qty": "8507"
        },
        {
          "no": "18",
          "price": "89.35",
          "qty": "12157"
        },
        {
          "no": "24",
          "price": "89.40",
          "qty": "17005"
        }
      ],
      "bidValues": [
        {
          "no": "10",
          "price": "89.15",
          "qty": "4779"
        },
        {
          "no": "82",
          "price": "89.10",
          "qty": "53802"
        },
        {
          "no": "69",
          "price": "89.05",
          "qty": "64430"
        },
        {
          "no": "390",
          "price": "89.00",
          "qty": "176882"
        },
        {
          "no": "17",
          "price": "88.95",
          "qty": "10078"
        }
      ],
      "delta": "0.00",
      "gamma": "0.00",
      "iv": "0.00",
      "ltt": "05/09/2023 12:33:44",
      "lttUTC": "05/09/2023 07:03:44",
      "symbol": "10753_NSE",
      "taq": "5471990",
      "tbq": "1778050",
      "theta": "0.00",
      "vega": "0.00"
    },
    "streaming_type": "quote2"
  }
}

Response Schema

Status Code 200

Name	Type	Description
askValues	[object]	Get List of AskValues .
no	string	Sequence number for Bid/Ask
price	string	Price asked for trading.
qty	string	Quantity asked for trading.
bidValues	[object]	Get List of BidValues .
no	string	Sequence number for Bid/Ask
price	string	Price asked for trading.
qty	string	Quantity asked for trading.
delta	string	the change in an option’s price with respect to the underlying asset’s price movements.
gamma	string	Gamma is an Option Chain Greek
iv	string	Implied Volatility is the expected volatility in a stock or security or asset
ltt	string	Last transaction time in milliseconds
lttUTC	string	Last transaction time in UTC time zone format
symbol	string	Actual symbol name of the scrip
taq	string	Total ask quantity
tbq	string	Total bid quantity
theta	string	change in an options contract's price with respect to the time left for expiry
vega	string	the value of an options contract has a positive correlation

Streaming Quote Data

Code samples

import websocket

def on_message(ws, msg):
print ("Message Arrived:" + msg)

def on_error(ws, error):
print (error)

def on_close(ws):
print ("Connection Closed")

def on_open(ws):
print ("Sending json")
data='{"request":{"streaming_type":"quote", "data":{"symbols":[{"symbol":"532826_BSE"}]}, "request_type":"subscribe", "response_format":"json"}}'
ws.send(data)
ws.send("\n")

headers = {'x-session-token':'12a8a2b304142425a1e52f109ff02cb2'}

websocket.enableTrace(True)

ws = websocket.WebSocketApp("wss://stream.stocknote.com", on_open = on_open, on_message = on_message, on_error = on_error, on_close = on_close, header = headers)

ws.run_forever()

wss:/stream.stocknote.com

Samco Trade API platform provides the Broadcast API, as the most effective way to receive quote data for instruments across all exchanges during live market hours. The API provides continuous streaming data of quote based on user request, and primarily consists of fields such as last traded price, open, high, low, close, last traded quantity, last traded volume, last traded time etc.

The API uses WebSocket protocol to establish a dedicated TCP connection after an HTTP handshake to receive streaming quotes and thereby provides seamless streaming of quote data. You need to use a WebSocket client to connect to our broadcast API. If you have already subscribed to our Samco Trade API services, you will be able to access broadcast API too.

Body parameter

requestBody={
  "streaming_type": "quote",
  "symbols": "[{'symbol':'-53'},{'symbol':'89017_NFO'}]",
  "request_type": "subscribe",
  "response_format": "JSON"
}

Parameters

Name	Type	Required	Description
body	object	false	none
streaming_type	string	true	Streaming type.Added for future use.Pass this value as “quote” always
symbols	[string]	true	List of symbols contains listing nos used to get quote.
request_type	string	true	Request type.This can be Subscribe/Unsubscribe. Subscribe - Receive continuous quote data. UnSubscribe - Stop receiving the continuous quote data. *It's important to unsubscribe when the streaming is no longer needed.
response_format	string	true	Response data format. Currently supports json only

Example responses

200 Response

{
  "aPr": "44561.00",
  "bPr": "44554.00",
  "aSz": "1",
  "bSz": "1",
  "sym": "2885_NSE",
  "avgPr": "44371.85",
  "c": "44119.00",
  "h": "44786.00",
  "l": "43969.00",
  "o": "44105.00",
  "oI": "361290",
  "oIChg": "22350.00",
  "ch": "435.00",
  "chPer": "0.99",
  "lTrdT": "01 Oct 2019, 06:47:03 PM",
  "ltp": "44554.00",
  "ltq": "1",
  "ltt": "01 Oct 2019, 06:47:03 PM",
  "lttUTC": "01 Oct 2019, 01:17:03 PM",
  "tBQ": "973",
  "tSQ": "610",
  "ttv": "782763833.41",
  "vol": "782763833.41",
  "yH": "44786.00",
  "yL": "0.00",
  "streaming_type": "quote"
}

Response Schema

Status Code 200

Name	Type	Description
aPr	string	Ask Price that seller willing to take for the scrip
bPr	string	Bid Price that buyer willing to pay for the scrip
aSz	string	Ask size/quantity for trading
bSz	string	Bid size/quantity for trading
sym	string	Actual symbol name of the scrip
avgPr	string	Average trading price of the equity or derivative
c	string	Close value of market snapshot
h	string	High value of market snapshot
l	string	Low value of market snapshot
o	string	Opening price of a market snapshot
oI	string	Open interest is the total number of outstanding derivative contracts that have not been settled
oIChg	string	open interest changed value
ch	string	Change value is the difference between the current value and the previous day's market close
chPer	string	Percentage of change between the current value and the previous day's market close
lTrdT	string	Time of the last transaction
ltp	string	Price at which last transaction / trade is done
ltq	string	Quantity of last transaction
ltt	string	Last transaction time in milliseconds
lttUTC	string	Last transaction time in UTC time zone format
tBQ	string	Total quantity of BUY transaction
tSQ	string	Total quantity of SELL transaction
ttv	string	Total volume of trading done
vol	string	Total amount of a security traded Today
yH	string	52 week high
yL	string	52 week low
streaming_type	string	Streaming type. Added for future use.Pass this value as “quote” always

User Logout

Code samples

var headers = {
  'Accept':'application/json',
  'x-session-token':'3f38c6dd6b950e48a23ebd16b04eb74e'

};

$.ajax({
  url: 'https://tradeapi.samco.in/logout',
  method: 'delete',

  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Accept': 'application/json',
  'x-session-token': '3f38c6dd6b950e48a23ebd16b04eb74e'
}

r = requests.delete('https://tradeapi.samco.in/logout'
, headers = headers)

print r.json()

DELETE /logout

Logging out user from the application

Parameters

Name	Type	Required	Description

Example responses

200 Response

{
  "serverTime": "12/12/19 16:20:11",
  "msgId": "786cdd94-2fc9-4c38-8f14-672ec64dd032",
  "status": "Success",
  "statusMessage": "Request successful"
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	Response status. Can be Success or Failure
statusMessage	string	status Message

Samco Publisher

Easily copy and paste trade buttons to embed them on your website.

What is its purpose?

Integrating buttons into websites and apps to enable users to execute trades. The Samco Publisher buttons can seamlessly become part of your website by copying and pasting a few lines of HTML and JavaScript code.

Why?

Enhance the user experience for your audience, whether they're readers of your financial blog or consumers of your market analysis. Offer them a unique trading experience while also presenting the opportunity for additional revenue for you.

Is there any fees?

No, Samco Publisher is available free of charge.

How do I get my trade buttons?

First create a Publisher app and obtain API keys via /publihser/createApp API. Use these keys along with the necessary HTML/Javascript lines to embed buttons on your website as documented here.

Create App

Code samples

var headers = {
  'Content-Type':'application/json',
  'Accept':'application/json'
};

$.ajax({
  url: 'https://tradeapi.samco.in/publisher/createApp',
  method: 'post',
  data: JSON.stringify(requestBody),
  headers: headers,
  success: function(data) {
    console.log(JSON.stringify(data));
  },
  error : function(error){
    console.log(error);
  }
})

import requests
headers = {
  'Content-Type': 'application/json',
  'Accept': 'application/json'
}

r = requests.post('https://tradeapi.samco.in/publisher/createApp'
, data=json.dumps(requestBody)
, headers = headers)

print r.json()

POST /publisher/createApp

This Publisher create API is to create a Publisher app and obtain API keys.

Body parameter

requestBody={
  "appName": "My App",
  "redirectURL": "https://www.example.com/",
  "description": "Description about the App"
}

Parameters

Name	Type	Required	Description
body	object	false	none
appName	string	true	Name of the App. you want to create
redirectURL	string	true	Wherever you want to redirect the page after order execution.
description	string	true	Description about the App

Example responses

200 Response

{
    "serverTime": "06/02/24 14:02:03",
    "msgId": "d3001338-4312-45ca-8195-9edc6873577a",
    "status": "Success",
    "apiKey": "5TmpmCtzBnxq2MbDb",
    "statusMessage": "Publisher App created & api key generated"
}

Response Schema

Status Code 200

Name	Type	Description
serverTime	string	Time at Server.
msgId	string	This is a unique identifier for every request into the system. Please quote this identifier to the support team if you face issues with the API request.
status	string	Login Success or Failure.
statusMessage	string	status Message
apiKey	string	apiKey is required while creating HTML / JSON trade button.

Offsite order execution

The offsite order execution functionality enables users to be redirected to Samco's order execution page from your application, allowing them to seamlessly place orders and return, similar to a payment gateway. This eliminates the need for you to develop or upkeep order execution screens. Samco's Publisher program leverages offsite order execution to offer embeddable Javascript+HTML trade buttons, eliminating the need for any API integrations.

Code Sample

Example JSON basket

let json_data = [
  {
    "transaction_type": "BUY",
    "exchange": "NSE",
    "trading_symbol": "TCS",
    "order_type": "MARKET",
    "quantity": 10
  },
  {
    "transaction_type": "SELL",
    "exchange": "NFO",
    "trading_symbol": "NIFTY24FEBFUT",
    "order_type": "LIMIT",
    "price": 21803,
    "quantity": 50
  },
  {
    "transaction_type": "BUY",
    "exchange": "NSE",
    "trading_symbol": "IDEA",
    "order_type": "LIMIT",
    "product": "CO",
    "price": 14.15,
    "quantity": 1,
    "trigger_price": 13
  }
]

Post the JSON data

<form
  method="post"
  id="basket-form"
  action="https://web2.samco.in/publisher/basket"
>
  <input type="hidden" name="api_key" value="xxx" />
  <input type="hidden" id="basket" name="data" value="" />
</form>

<script>
  document.getElementById("basket").value = JSON.stringify(json_data);
  document.getElementById("basket-form").submit();
</script>

Please review the code sample on the right for preparing orders and submitting the JSON basket data via an HTML form.

Sending multiple orders is feasible, where users confirm them via a shopping basket-like interface. To do this, you need to assemble a JSON list of stocks to be traded, complete with the necessary order parameters. Then, POST this list as a form field named data along with your api_key to https://web2.samco.in/publisher/basket.

This request needs to happen on the user's device, either through a web browser or a mobile app's webview. While the backend can handle preparing the shopping basket, the easiest way to send the request is by creating a hidden form, adding the JSON data to it, and using JavaScript to submit it automatically.

If you're setting up the basket directly on your web application, you can simplify the process by utilizing Samco's Publisher JavaScript plugin.

Request parameters

Name	Type	Required	Description
body	object	false	none
trading_symbol	string	true	Pass "symbol" in "trading_symbol" parameter for Equity Cash symbols and "Trading Symbol" for all the F&O contracts ('symbol' and 'tradingSymbol' is available in ScripMaster.csv).
exchange	string	true	Name of the exchange. Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
transaction_type	string	true	Transaction type should be BUY or SELL
order_type	string	true	Type of order. It can be one of the following, MARKET - Market Order,LIMIT - Limit Order, SL - Stop Loss Limit, SL-M - Stop loss market
quantity	string	true	Quantity with which order is being placed
product	string	false	Product Type of the order. It can be CNC (Cash and Carry), NRML (Normal), MIS (Intraday), CO, BO, If not passed default will be CNC
price	string	true	Price at which the order will be placed
trigger_price	string	false	The price at which an order should be triggered in case of SL, SL-M
disclosed_quantity	string	true	If provided should be minimum of 10% of actual quantity
validity	string	true	Order validity can be DAY / IOC. Day is an order type which is valid for the whole trading day and stays pending till it is executed in respective trading day.
is_amo	string	true	After Market Order Flag YES/NO (1/0)

JS Plugin

The Samco Publisher JavaScript plugin allows you to integrate one-click trade buttons into your webpage. Operating similar to a combination of a shopping basket and a payment gateway, it initiates a new window on your webpage, assisting users through the trading process before returning them to your page.

Using the JavaScript plugin, you have the flexibility to dynamically add one or more stocks to the basket, with a maximum limit of 10. Alternatively, you can embed straightforward static buttons using plain HTML for a simpler approach.

Create your buttons

<script src="https://web2.samco.in/publisher.js?v=1"></script>

To integrate Samco Publisher into your webpage, simply insert the above script tag at the end of your webpage, right before the closing tag. You only need to include this script once, and it will enable the rendering of any number of buttons on the page.

Branded HTML5 buttons

<!--  Here's a simple HTML link that would initiate a market buy of the IDEA stock:  -->
<samco-button
  href="#"
  data-samco="your-api-key"
  data-exchange="NSE"
  data-trading_symbol="IDEA"
  data-transaction_type="BUY"
  data-quantity="1"
  data-order_type="MARKET"
  >Buy IDEA stock</samco-button>

To render branded Samco buttons that initiate a trade with a single click, you can use the custom HTML5 tag . These buttons function similarly to social media buttons and can be included as many times as needed on a page.

Custom HTML5 buttons

<!--  Here's a simple HTML link that would initiate a MARKET BUY of the IDEA stock:  -->
<a
  href="#"
  data-samco="your-api-key"
  data-exchange="NSE"
  data-transaction_type="BUY"
  data-trading_symbol="IDEA"
  data-order_type="MARKET"
  data-quantity="1"
  >Buy IDEA stock</a>


<!--  Here's a simple HTML button that would initiate a LIMIT SELL of the TCS stock: //-->
<button
  data-samco="your-api-key"
  data-exchange="NSE"
  data-transaction_type="SELL"
  data-trading_symbol="TCS"
  data-order_type="LIMIT"
  data-quantity="1"
  data-price="4095"
>
  Sell TCS
</button>

<!--  Here's a simple HTML button that would initiate a CO order of the RELIANCE stock: //-->
<button
  data-samco="your-api-key"
  data-exchange="NSE"
  data-transaction_type="BUY"
  data-trading_symbol="RELIANCE"
  data-order_type="LIMIT"
  data-quantity="1"
  data-product="CO"
  data-price="2860"
  data-trigger_price="2840"
>
  Buy RELIANCE (Cover Order)
</button>

You can leverage HTML5 data attributes on any HTML element to transform it into a trade button, which can then be activated with a single click. The examples below demonstrate how a link and a button can be converted into trade buttons.

Generating dynamic buttons with Javascript

Dynamic buttons with Javascript


<!-- A Samco button will be generated within the specified container. //-->
<p id="default-button"></p>

<!-- The basket will be linked to the 'onClick' event of this element. //-->
<button id="custom-button">Buy the basket</button>

<!-- Include the plugin //-->
<script src="https://web2.samco.in/js/publisher/publisher.js?v=1"></script>

<script>
  // Only run your custom code once SamcoPublisher has fully initialised.
  // Use SamcoPublisher.ready() to achieve this.
  SamcoPublisher.ready(function () {
    // Initialize a new Publisher instance.
    // You can initialize multiple instances if you need.
    var publisher = new SamcoPublisher("your-api-key");

    // Add a stock to the basket
    publisher.add({
      exchange: "NSE",
      transaction_type: "BUY",
      trading_symbol: "IDEA",
      order_type: "MARKET",
      quantity: 1,
    });

    // Add another stock (Intra day)
    publisher.add({
      exchange: "NSE",
      transaction_type: "SELL",
      trading_symbol: "TCS",
      order_type: "LIMIT",
      quantity: 1,
      price: 4080,
      product: "MIS"
    });

    //Add a Cover Order
    publisher.add({
      exchange: "NSE",
      transaction_type: "BUY",
      trading_symbol: "RELIANCE",
      order_type: "LIMIT",
      product: "CO",
      price: 2862.5,
      quantity: 1,
      stoploss: 2850
    });

    //Add a Bracket Order
    publisher.add({
      exchange: "NSE",
      transaction_type: "BUY",
      trading_symbol: "SBIN",
      order_type: "LIMIT",
      product: "BO",
      quantity: 1,
      squareoff : 680,
      price: 670,
      stoploss: 660,
      trailing_stoploss : 5
    });

    // Register an (optional) callback.
    publisher.finished(function (status) {
      alert("Finished. Status is " + status);
    });

    // Render the in-built button inside a given target
    publisher.renderButton("#default-button");

    // OR, link the basket to any existing element you want
    publisher.link("#custom-button");
  });
</script>

You have the option to create a basket of stocks and have the plugin render a Samco button that executes it. Alternatively, you can link the basket to your own button or any HTML element of your choice.

To ensure proper initialization of your custom SamcoPublisher calls, it's essential to execute them after the plugin's assets have loaded asynchronously. You can achieve this by utilizing the SamcoPublisher.ready() function. This function ensures that your custom calls are executed only when the plugin is fully loaded and ready to be utilized.

Parameters

Name	Type	Required	Description
body	object	false	none
trading_symbol	string	true	Pass "symbol" in "trading_symbol" parameter for Equity Cash symbols and "Trading Symbol" for all the F&O contracts ('symbol' and 'tradingSymbol' is available in ScripMaster.csv).
exchange	string	true	Name of the exchange. Valid exchanges values (BSE/ NSE/ NFO/ MCX/ CDS).If the user does not provide an exchange name, by default considered as NSE.For trading with BSE, NFO, CDS and MCX, exchange is mandatory.
transaction_type	string	true	Transaction type should be BUY or SELL
order_type	string	true	Type of order. It can be one of the following, MARKET - Market Order,LIMIT - Limit Order, SL - Stop Loss Limit, SL-M - Stop loss market
quantity	string	true	Quantity with which order is being placed
product	string	false	Product Type of the order. It can be CNC (Cash and Carry), NRML (Normal), MIS (Intraday), CO, BO, If not passed default will be CNC
price	string	true	Price at which the order will be placed
trigger_price	string	false	The price at which an order should be triggered in case of SL, SL-M
disclosed_quantity	string	true	If provided should be minimum of 10% of actual quantity
validity	string	true	Order validity can be DAY / IOC. Day is an order type which is valid for the whole trading day and stays pending till it is executed in respective trading day.
is_amo	string	true	After Market Order Flag YES/NO (1/0)

Methods

Method	Arguments	Description
body	false	none
SamcoPublisher.ready()	function()	A secure wrapper for all API calls that asynchronously waits for all assets to load.
add()	entry	It incorporates an object literal {} containing the parameters outlined in the preceding section, representing a single trading entry, into the basket.
get()		Returns an array[] of all added entries.
count()		Returns the number of added entries.
setOption()	key, value	Sets the value for certain supported keys.
renderButton()	element_selector	It displays a branded Samco button within the specified target element. When clicked, this button initiates the transaction in a new window tab. The element_selector refers to an HTML selector, such as #buy-button or .buttons.
link()	element_selector	Associates the basket with the designated HTML element, enabling the initiation of the transaction in a new window tab upon clicking. The element_selector denotes an HTML selector, such as #buy-button or .buttons.
html()		Generates an HTML form with the required hidden fields and the basket payload serialized. You can append this form to the document body and submit it to initiate the transaction.
finished()	function(status)	Set up a callback function that activates after the order placement process is completed.

Samco Trade API Documentation v3.0

Http Request Header

Http Response Code

Trade Limits

Rate Limits - March 2024

User Login

User Login

Parameters

Response Schema

Personal Index

Index Data

Parameters

Response Schema

Market Depth

Market Depth

Parameters

Response Schema

GTT Order

Add GTT

Parameters

Response Schema

Modify GTT

Parameters

Response Schema

Delete GTT

Parameters

Response Schema

Add OCO

Here’s how it works?

Parameters

Response Schema

Modify OCO

Parameters

Response Schema

Delete OCO

Parameters

Response Schema

List GTT OCO

Parameters

Response Schema

Span Margin

Span Margin

Parameters

Response Schema

Quote

Index Quote

Parameters

Response Schema

Get Quote

Parameters

Response Schema

Multi Quote

Parameters

Response Schema

Search Equity & Derivative

Search Equity scrips

Parameters

Response Schema

Option

Option Chain

Parameters

Response Schema

Future

Future Chain

Parameters

Response Schema

User Limits

User Limits

Response Schema

Orders

Place Order

Parameters

Response Schema

Place BO Order

Parameters

Response Schema

Place CO Order

Parameters

Response Schema

Get Order Status
